flow 0

68.4 mm x 32.5 mm
66 mm x 32.5 mm

Package Picture

Possible features

  • Clip-in, reliable mechanical connection, qualified for wave soldering
  • Convex shaped substrate for superior thermal contact
  • Thermo-mechanical push-and-pull force relief
  • No PCB hole damage to enable reuse
  • Reliable cold welding connection to PCB
  • Convex shaped substrate for superior thermal contact
More about flow 0
  • Topology
  • Sub-Topology
  • Product line
  • Voltage
    in V
  • Current
    in A
  • Main Chip technology
  • Height
    in mm
0 Products
Download Selection
View
Part-No Product status Topology Sub-Topology Product line Voltage

in V
Current

in A
Main Chip technology Housing family Height in

mm
Isolation Module datasheet
10-FZ071SA050SM02-L524L18 Series production PFC (Three-phase applications) SPFC-KE-Cap-NTC flowSPFC 0 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
SPFC-KE-Cap-NTC
flowSPFC 0
10-FZ071SA075SM02-L525L18 Series production PFC (Three-phase applications) SPFC-KE-Cap-NTC flowSPFC 0 650 75 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
SPFC-KE-Cap-NTC
flowSPFC 0
10-FZ071SA100SM02-L526L18 Series production PFC (Three-phase applications) SPFC-KE-Cap-NTC flowSPFC 0 650 100 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
SPFC-KE-Cap-NTC
flowSPFC 0
10-F012PNA015M7-P840C29 Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 15 IGBT M7 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-FZ12NMA080SH23-M260F03 In qualification Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
V23990-P623-F24-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 600 50 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
V23990-P625-F24-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 600 100 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
10-FZ07NIA060SM-P926F43 In qualification Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 60 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
V23990-P624-F24-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 600 75 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
V23990-P729-F48-PM Series production H-Bridge H-Bridge-KE-Cap-NTC fastPACK 0 H C 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-Cap-NTC
fastPACK 0 H C
10-PZ07BVA020SM-LD44E08Y Series production H6.5 Booster + H6.5-KE-NTC flowSOL 0 BI (TL) 650 20 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Booster + H6.5-KE-NTC
flowSOL 0 BI (TL)
10-FZ127PA008SC-L156E08 Series production Sevenpack IB-OE-NTC flow7PACK 0 1200 8 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
IB-OE-NTC
flow7PACK 0
V23990-P629-F48-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
10-FZ127PA015SC-L158E08 Series production Sevenpack IB-OE-NTC flow7PACK 0 1200 15 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
IB-OE-NTC
flow7PACK 0
10-FZ127PA025SC-L159E08 Series production Sevenpack IB-OE-NTC flow7PACK 0 1200 25 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
IB-OE-NTC
flow7PACK 0
10-P012NME080SH-M910F09Y Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 IGBT4 HS flow 0 17 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
V23990-P541-B28-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 6 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P629-L99Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 17 AlN Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
V23990-P629-L58-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
V23990-P541-D129-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 6 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P629-L58Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-PC094PB017ME02-L620F36Y Series production H-Bridge H-Bridge-OE-KE-Cap-NTC fastPACK 0 SiC 900 80 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-OE-KE-Cap-NTC
fastPACK 0 SiC
V23990-P541-C29-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 6 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P541-B129-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 6 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ07BIA030S5Y-P894E78 Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT S5 flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
V23990-P541-A29-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 6 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P541-D28-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 6 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P729-F49-PM Series production H-Bridge H-Bridge-KE-Cap-NTC fastPACK 0 H C 1200 40 IGBT4 HS flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-Cap-NTC
fastPACK 0 H C
V23990-P729-F56-PM Series production H-Bridge H-Bridge-KE-Cap-NTC fastPACK 0 H C 1200 25 IGBT2 flow 0 17 AlN Module datasheet:PDF
H-Bridge-KE-Cap-NTC
fastPACK 0 H C
V23990-P627-F88-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 1200 15 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
10-P006PPA010SB-M683BY Series production PIM+PFC (CIP) CIP-OE-Shunt-NTC flowPIM® 0 + PFC 600 10 Infineon CoolMOS™ C6 flow 0 17 Al2O3 Module datasheet:PDF
CIP-OE-Shunt-NTC
flowPIM 0 + PFC
V23990-P867-F48-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 1200 10 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P867-F49-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 1200 10 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P629-L49Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-PZ07BIA030SG-P894E38Y Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT3 HS flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
V23990-P640-G-PM Series production Rectifier (+Brake) 3ph-Rectifier-BRC flowCON 0 1600 75 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC
flowCON 0
V23990-P627-F89-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 1200 15 IGBT4 HS flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
10-PZ07BIA030RW-P894E88Y Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT fast flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
V23990-P640-H-PM Series production Rectifier (+Brake) 3ph-Rectifier flowCON 0 1600 75 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Rectifier
flowCON 0
10-FZ07BIA030SG-P894E38 Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT3 HS flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
V23990-P649-G-PM Series production Rectifier (+Brake) 3ph-Rectifier-BRC flowCON 0 1600 50 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC
flowCON 0
V23990-P840-A58Y-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 15 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ07BIA030RW-P894E88 Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT fast flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
V23990-P649-H-PM Series production Rectifier (+Brake) 3ph-Rectifier flowCON 0 1600 50 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Rectifier
flowCON 0
V23990-P840-A48-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 15 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ12NMA080SM01-L740F58 Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-Cap-NTC flowMNPC 0 1200 80 Trench Field Stop IGBT flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-Cap-NTC
flowMNPC 0
V23990-P840-C49-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 15 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P849-A48-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 8 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-F0062TA099FS-P980D59 Series production PFC (Single-phase applications) Dual Boost PFC-Half Controlled-Shunt-Cap-NTC flowPFC 0 600 18 Infineon CoolMOS™ C6 flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost PFC-Half Controlled-Shunt-Cap-NTC
flowPFC 0
V23990-P862-F49-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 600 15 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P590-J19-PM Series production Rectifier (+Brake) 1ph-Half Controlled flowCON 0 1600 75 Thyristor (SCR) flow 0 17 Al2O3 Module datasheet:PDF
1ph-Half Controlled
flowCON 0
10-FZ07BIA030SM01-P894E68 Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
V23990-P840-A59-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 15 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P600-I19-PM Series production Rectifier (+Brake) Modular Half Controlled-BRC flowCON 0 1600 75 Thyristor (SCR) flow 0 17 Al2O3 Module datasheet:PDF
Modular Half Controlled-BRC
flowCON 0
V23990-P840-C59-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 15 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P640-G10-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flowCON 0 1600 42 Thyristor (SCR) flow 0 17 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flowCON 0
V23990-P849-C59-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 8 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P640-H10-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flowCON 0 1600 42 Thyristor (SCR) flow 0 17 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flowCON 0
10-FZ12NMA080NS03-M260F38 Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 Trench Field Stop II IGBT flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
10-F006NPA070FP-P969F09 Series production Three-level NPC (I-Type) NPC-KE-Parallel-NTC flowNPC 0 parallel 1200 75 NPT IGBT flow 0 17 Al2O3 Module datasheet:PDF
NPC-KE-Parallel-NTC
flowNPC 0 parallel
V23990-P649-G10-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flowCON 0 1600 34 Thyristor (SCR) flow 0 17 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flowCON 0
10-PZ12NMA080NS03-M260F38Y Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 Trench Field Stop II IGBT flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
10-PZ06NRA075FU-P969F08Y Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 75 Trench Field Stop IGBT flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
V23990-P649-H10-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flowCON 0 1600 34 Thyristor (SCR) flow 0 17 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flowCON 0
V23990-P848-C59-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 4 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-PZ06NPA070FP01-P969F10Y Series production Three-level NPC (I-Type) NPC-KE-Parallel-NTC flowNPC 0 parallel 1200 75 NPT IGBT flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-Parallel-NTC
flowNPC 0 parallel
V23990-P546-B28-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ07NBA075SM-P916L58 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 symmetric 650 75 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 symmetric
V23990-P541-B138-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 6 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ07NIA075SM-P926F58 Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 75 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
V23990-P541-D138-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 6 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-PZ12NMA080SH23-M260F03Y Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
V23990-P546-B128-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-PZ12NMA080NS07-M260F78Y In qualification Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 Trench Field Stop II IGBT flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
V23990-P546-A29-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P546-C29-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P623-F58-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
V23990-P590-J09-PM Series production Rectifier (+Brake) 1ph-Rectifier flowCON 0 1600 105 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
1ph-Rectifier
flowCON 0
V23990-P546-D28-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P600-I09-PM Series production Rectifier (+Brake) Modular Rectifier-BRC flowCON 0 1600 105 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
Modular Rectifier-BRC
flowCON 0
V23990-P546-C28-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-PF12NMA080SH08-M260F98T Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
V23990-P629-L98-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 12 AlN Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ062TA099FS05-P980D68 Series production PFC (Single-phase applications) Dual Boost PFC-CSC-Shunt-Cap-NTC flowPFC 0 CD 600 18 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost PFC-CSC-Shunt-Cap-NTC
flowPFC 0 CD
V23990-P840-A58-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 15 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P848-A48-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 4 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P544-B28-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 15 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P849-A58-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 8 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P544-B129-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 15 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P544-A29-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 15 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P864-F48-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 600 30 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P544-B128-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 15 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P865-F48-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 600 50 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P866-F48-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 600 75 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P869-F48-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 1200 25 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
10-FZ06BIA083FI-P896E Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (T) primary 600 30 Infineon CoolMOS™ CFD2 flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (T) primary
V23990-P544-C29-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 15 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P860-F48-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 1200 35 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
10-FZ07BVA030S5-LD45E08 In qualification H6.5 Booster + H6.5-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT S5 flow 0 12 Al2O3 Module datasheet:PDF
Booster + H6.5-KE-NTC
flowSOL 0 BI (TL)
V23990-P864-F49-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 600 30 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P861-F49-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 600 10 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P865-F49-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 600 50 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
10-PC06PPA010SB-M683B06Y Series production PIM+PFC (CIP) CIP-OE-Shunt-NTC flowPIM® 0 + PFC 600 10 IGBT3 LL flow 0 12 Al2O3 Module datasheet:PDF
CIP-OE-Shunt-NTC
flowPIM 0 + PFC
V23990-P868-F49Y-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 1200 15 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P869-F49-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 1200 25 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P860-F49-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 1200 35 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P865-F48Y-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 600 50 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P629-L63Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
V23990-P866-F48Y-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 600 75 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
10-FZ06NIA075SA-P926F33 Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 75 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
10-P0166BA050RW-LD59G09Y Series production Rectifier (+Brake) 3ph-Non Controlled-BRC-KE-NTC flowCON 0 1600 50 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Non Controlled-BRC-KE-NTC
flowCON 0
10-PD166BA050RW-LD59G07Y Series production Rectifier (+Brake) 3ph-Non Controlled-BRC-KE-NTC flowCON 0 1600 50 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Non Controlled-BRC-KE-NTC
flowCON 0
V23990-P541-A28-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 6 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ062TA030SM-P986D13 Series production PFC (Single-phase applications) Dual Boost PFC-CSC-Shunt-Cap-NTC flowPFC 0 CD 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost PFC-CSC-Shunt-Cap-NTC
flowPFC 0 CD
V23990-P543-A28-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 10 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P544-A28-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 15 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ062TA050SM-P987D13 Series production PFC (Single-phase applications) Dual Boost PFC-CSC-Shunt-Cap-NTC flowPFC 0 CD 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost PFC-CSC-Shunt-Cap-NTC
flowPFC 0 CD
V23990-P545-A28-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P546-A28-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P549-A-PM Not recommended for new designs PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 8 IGBT3 LL flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P849-A59Y-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 8 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P546-A38-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P540-A-PM Not recommended for new designs PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 15 IGBT3 LL flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P545-A20-PM Not recommended for new designs PIM (CIB) CIB-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P543-A39-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 10 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ062TA099FH01-P980D28 Series production PFC (Single-phase applications) Dual Boost PFC-Half Controlled-CSE-Shunt-Cap-NTC flowPFC 0 CD 600 30 Infineon CoolMOS™ CP flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost PFC-Half Controlled-CSE-Shunt-Cap-NTC
flowPFC 0 CD
10-PC094PB065ME01-L637F06Y Series production H-Bridge 2xHalf Bridge-KE-NTC fastPACK 0 SiC 900 20 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
2xHalf Bridge-KE-NTC
fastPACK 0 SiC
V23990-P546-A20-PM Not recommended for new designs PIM (CIB) CIB-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P549-C01-PM Not recommended for new designs PIM (CIB) CI-OE-NTC flowPIM® 0 1200 10 IGBT3 LL flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-FZ06NPA045FP-P967F Series production Three-level NPC (I-Type) NPC-KE-Parallel-NTC flowNPC 0 parallel 1200 50 Parallel Switch flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-Parallel-NTC
flowNPC 0 parallel
V23990-P540-A01-PM Not recommended for new designs PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 15 IGBT3 LL flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P544-A20-PM Not recommended for new designs PIM (CIB) CIB-OE-NTC flowPIM® 0 600 15 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ06NPA045FP01-P967F10 Series production Three-level NPC (I-Type) NPC-KE-Parallel-NTC flowNPC 0 parallel 1200 50 Parallel Switch flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-Parallel-NTC
flowNPC 0 parallel
V23990-P540-C01-PM Not recommended for new designs PIM (CIB) CI-OE-NTC flowPIM® 0 1200 15 IGBT3 LL flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-FZ06NPA070FP01-P969F10 Series production Three-level NPC (I-Type) NPC-KE-Parallel-NTC flowNPC 0 parallel 1200 75 Parallel Switch flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-Parallel-NTC
flowNPC 0 parallel
V23990-P545-A21-PM Not recommended for new designs PIM (CIB) CIB-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P545-C21-PM Not recommended for new designs PIM (CIB) CI-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-PZ07ANA100RG02-LK39L88Y In qualification PFC (Three-phase applications) ANPFC-KE-Cap-NTC flowANPFC 0 650 100 IGBT fast flow 0 12 Al2O3 Module datasheet:PDF
ANPFC-KE-Cap-NTC
flowANPFC 0
V23990-P546-C39-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P546-C38-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P546-A39-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ07LBA100SM03-L705L08 In qualification PFC (Three-phase applications) NPFC-Cap-NTC flowNPFC 0 650 100 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
NPFC-Cap-NTC
flowNPFC 0
V23990-P549-A01-PM Not recommended for new designs PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 10 IGBT3 LL flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ06NIA050SA-P925F33 Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 50 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
10-FZ07NBA030SM01-P914L53 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 symmetric 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 symmetric
10-PZ06NIA030SA-P924F33Y Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 30 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
V23990-P541-A20-PM Not recommended for new designs PIM (CIB) CIB-OE-NTC flowPIM® 0 600 6 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-PZ06NIA075SA-P926F33Y Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 75 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
10-FZ074PA030SM-L623F08 Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 0 H C 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 0 H C
V23990-P545-C38-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-FZ062TA040FB-P984D18 Series production PFC (Single-phase applications) Dual Boost PFC-CSC-Shunt-Cap-NTC flowPFC 0 CD 600 50 IGBT2 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost PFC-CSC-Shunt-Cap-NTC
flowPFC 0 CD
10-FZ074PA050SM-L624F08 Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 0 H C 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 0 H C
V23990-P545-C39-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-FZ07B2A030SM02-M575L48 Series production Booster Dual Boost-KE-Cap-NTC flowBOOST 0 dual 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-Cap-NTC
flowBOOST 0 dual
10-FZ074PA075SM-L625F08 Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 0 H C 650 75 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 0 H C
V23990-P545-B28-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P545-B128-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-PZ06O2A030FW-LH02J08Y Series production Ultrafast Rectifier 1ph-Non-Controlled–NTC flowCON 0 600 30 Fast diode flow 0 12 Al2O3 Module datasheet:PDF
1ph-Non-Controlled–NTC
flowCON 0
V23990-P545-A29-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P545-A39-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P545-B129-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ06NBA084FP10-M306L38 Series production Booster Symmetric Symm. Boost-KE-Parallel-NTC flowBOOST 0 symmetric 600 84 Trench Field Stop IGBT flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Parallel-NTC
flowBOOST 0 symmetric
10-FZ07LBA100SM01-L705L18 Series production PFC (Three-phase applications) NPFC-Cap-NTC flowNPFC 0 650 100 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
NPFC-Cap-NTC
flowNPFC 0
V23990-P545-C29-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-FZ07NBA075SG10-M304L58 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 symmetric 650 75 Trench Field Stop IGBT flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 symmetric
V23990-P629-L43Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 50 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
V23990-P545-B38-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 20 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P640-G20-PM Series production Rectifier (+Brake) 3ph-Rectifier-BRC flowCON 0 1600 75 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC
flowCON 0
10-FZ074PA080CR-L622F68 Series production H-Bridge H-Bridge-OE-KE-Cap-NTC fastPACK 0 MOS 650 20 Infineon CoolMOS™ CFD2 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-OE-KE-Cap-NTC
fastPACK 0 MOS
V23990-P840-A49-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 15 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-PZ12ORA100RO-LH00J88Y In qualification Ultrafast Rectifier 1ph-Non-Controlled–NTC flowCON 0 1200 100 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
1ph-Non-Controlled–NTC
flowCON 0
10-PZ074PA080CR-L622F68Y Series production H-Bridge H-Bridge-OE-KE-Cap-NTC fastPACK 0 MOS 650 20 Infineon CoolMOS™ CFD2 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-OE-KE-Cap-NTC
fastPACK 0 MOS
V23990-P849-A49-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 8 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-PZ07NBA100SM10-M305L68Y Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 symmetric 650 100 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 symmetric
V23990-P849-C49-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 8 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P840-C58-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 15 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-P006NPA070FP-P969F09Y In qualification Three-level NPC (I-Type) NPC-KE-Parallel-NTC flowNPC 0 parallel 1200 75 NPT IGBT flow 0 17 Al2O3 Module datasheet:PDF
NPC-KE-Parallel-NTC
flowNPC 0 parallel
10-PZ06NBA041FS-P915L68Y Series production Booster Symmetric Symm. Boost-KE-Bypass diode-NTC flowBOOST 0 symmetric 600 40 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Bypass diode-NTC
flowBOOST 0 symmetric
V23990-P848-A59-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 4 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P849-A59-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 8 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P840-C48-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 15 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P848-A09-PM Not recommended for new designs PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 4 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ12NMA080SH-M269F Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
V23990-P849-A49Y-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 8 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ12NMA080SH01-M260F Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
10-FZ06NBA041FS01-P915L78 Series production Booster Symmetric Symm. Boost-KE-Bypass diode-NTC flowBOOST 0 symmetric 600 40 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Bypass diode-NTC
flowBOOST 0 symmetric
10-PZ12NMA080SH-M269FY Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
10-PZ12NMA080SH01-M260FY Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
V23990-P629-F72-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ07NIA100S502-P927F58 In qualification Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 1200 100 IGBT S5 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0
10-PZ123BA040MR01-M909L68Y In qualification Booster Triple Boost-KE-Cap-NTC flow3xBOOST 0 SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Triple Boost-KE-Cap-NTC
flow3xBOOST 0 SIC
10-FZ071SA075S501-L525L58 Series production PFC (Three-phase applications) SPFC-KE-NTC flowSPFC 0 650 75 IGBT S5 flow 0 12 Al2O3 Module datasheet:PDF
SPFC-KE-NTC
flowSPFC 0
10-PZ07NIA075S5-P926F53Y Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 75 IGBT S5 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
10-FZ07BBA075S5-L684L58 Series production Buck-Booster Symmetric Symm. Buck Boost-KE-NTC flowBUCK-BOOST 0 650 75 IGBT S5 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Buck Boost-KE-NTC
flowBUCK-BOOST 0
V23990-P543-B138-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 10 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P543-D138-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 10 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P546-A21-PM Not recommended for new designs PIM (CIB) CIB-OE-NTC flowPIM® 0 600 30 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P543-B129-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 10 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P543-B128-PM Not recommended for new designs PIM (CIB) CIB-OE-NTC flowPIM® 0 600 10 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P543-B28-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 10 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ06NRA060FU-P967F08 Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 75 IGBT UltraFast flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
10-FZ06NRA075FU-P969F08 Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 75 IGBT UltraFast flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
10-FZ06NRA069FP03-P967F78 Series production Three-level NPC (I-Type) NPC-KE-Parallel-NTC flowNPC 0 parallel 1200 75 Parallel Switch flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-Parallel-NTC
flowNPC 0 parallel
10-FZ06NBA110FP-M306L28 In qualification Booster Symmetric Symm. Boost-KE-Parallel-NTC flowBOOST 0 symmetric 600 110 Parallel Switch flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Parallel-NTC
flowBOOST 0 symmetric
10-PZ07NMA100SM-M265F58Y Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 650 100 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
10-PZ12NMA040SH-M267FY Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
10-F006PPA010SB-M683B Series production PIM+PFC (CIP) CIP-OE-Shunt-NTC flowPIM® 0 + PFC 600 10 IGBT3 LL flow 0 17 Al2O3 Module datasheet:PDF
CIP-OE-Shunt-NTC
flowPIM 0 + PFC
10-F006PPA015SB-M684B Series production PIM+PFC (CIP) CIP-OE-Shunt-NTC flowPIM® 0 + PFC 600 15 IGBT3 LL flow 0 17 Al2O3 Module datasheet:PDF
CIP-OE-Shunt-NTC
flowPIM 0 + PFC
10-F006PPA020SB-M685B Series production PIM+PFC (CIP) CIP-OE-Shunt-NTC flowPIM® 0 + PFC 600 20 IGBT3 LL flow 0 17 Al2O3 Module datasheet:PDF
CIP-OE-Shunt-NTC
flowPIM 0 + PFC
V23990-P640-H09-PM In qualification Rectifier (+Brake) 3ph-Rectifier flowCON 0 1600 75 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Rectifier
flowCON 0
10-F006PPA020SB01-M685B10 Series production PIM+PFC (CIP) CIP-OE-Shunt-NTC flowPIM® 0 + PFC 600 20 IGBT3 LL flow 0 17 Al2O3 Module datasheet:PDF
CIP-OE-Shunt-NTC
flowPIM 0 + PFC
V23990-P848-C48-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 4 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P848-C58-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 4 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P849-C58-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 8 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P848-A49-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 4 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P629-F73-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ12NMA040SH-M267F Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
V23990-P866-F49-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 600 75 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
10-PC094PB035ME02-L629F36Y Series production H-Bridge H-Bridge-OE-KE-Cap-NTC fastPACK 0 SiC 900 40 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-OE-KE-Cap-NTC
fastPACK 0 SiC
10-FZ06NBA084FP-M306L48 In qualification Booster Symmetric Symm. Boost-KE-Parallel-NTC flowBOOST 0 symmetric 600 84 Parallel Switch flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Parallel-NTC
flowBOOST 0 symmetric
10-FZ06NBA075SA-P916L33 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 symmetric 600 75 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 symmetric
10-FZ06NBA030SA-P914L33 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 symmetric 600 30 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 symmetric
10-PF07NIA100S505-P927F53T In qualification Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 1200 100 IGBT S5 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0
10-FZ06NBA050SA-P915L33 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 symmetric 600 50 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 symmetric
10-PF07NIA100RG-P927F86T In qualification Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 1200 100 IGBT fast flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0
V23990-P629-L59-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FU127PA008SC-L156E06 In qualification Sevenpack IB-OE-NTC flow7PACK 0 1200 8 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
IB-OE-NTC
flow7PACK 0
V23990-P629-L49-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ06NRA084FP02-P969F68 Series production Three-level NPC (I-Type) NPC-KE-Parallel-NTC flowNPC 0 parallel 1200 100 Parallel Switch flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-Parallel-NTC
flowNPC 0 parallel
10-FU127PA015SC-L158E06 In qualification Sevenpack IB-OE-NTC flow7PACK 0 1200 15 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
IB-OE-NTC
flow7PACK 0
10-FZ06NRA084FP03-P969F78 Series production Three-level NPC (I-Type) NPC-KE-Parallel-NTC flowNPC 0 parallel 1200 100 Parallel Switch flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-Parallel-NTC
flowNPC 0 parallel
10-FU127PA025SC-L159E06 In qualification Sevenpack IB-OE-NTC flow7PACK 0 1200 25 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
IB-OE-NTC
flow7PACK 0
10-FZ063BA040MF-M575L08 Series production Booster Triple Boost-KE-Cap-NTC flow3xBOOST 0 600 44 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
Triple Boost-KE-Cap-NTC
flow3xBOOST 0
10-F007NIA030SM-P965F39 In qualification Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 30 IGBT H5 flow 0 17 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
10-FZ06B2A040MF01-M575L28 Series production Booster Dual Boost-KE-Cap-NTC flowBOOST 0 dual 600 40 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-Cap-NTC
flowBOOST 0 dual
10-PZ12B2A040MR01-M330L68Y In qualification Booster Dual Boost-KE-Cap-NTC flowBOOST 0 dual SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-Cap-NTC
flowBOOST 0 dual SIC
10-FZ07NMA100SM-M265F58 Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 650 100 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
V23990-P629-L83-PM In qualification Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual SIC
10-FZ073BA030SM02-M575L38 Series production Booster Triple Boost-KE-Cap-NTC flow3xBOOST 0 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Triple Boost-KE-Cap-NTC
flow3xBOOST 0
V23990-P629-L81-PM In qualification Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual SIC
V23990-P629-L94-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 17 AlN Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ07NBA050SM-P915L58 In qualification Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 symmetric 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 symmetric
V23990-P629-L94Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 17 AlN Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
V23990-P868-F48-PM Series production Sixpack Inverter-KE-NTC flowPACK 0 1200 15 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
10-FZ06NIA030SA-P924F33 Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 30 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
V23990-P543-D129-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 10 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-F007NIA030SM01-P965F49 In qualification Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 30 IGBT H5 flow 0 17 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
V23990-P543-C29-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 10 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-PZ126PA080ME-M909F18Y Series production Sixpack 3xHalf Bridge-OE-KE-Cap-SO-NTC flowPACK 0 SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
3xHalf Bridge-OE-KE-Cap-SO-NTC
flowPACK 0 SiC
V23990-P543-A29-PM Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 600 10 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-PZ126PA080MR-M909F28Y Series production Sixpack 3xHalf Bridge-OE-KE-Cap-SO-NTC flowPACK 0 SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
3xHalf Bridge-OE-KE-Cap-SO-NTC
flowPACK 0 SiC
10-FZ06NRA045FH01-P965F10 Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 MOS 1200 30 Infineon CoolMOS™ CP flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 MOS
V23990-P543-C28-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 10 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-PZ123BA080ME-M909L18Y Series production Booster Triple Boost-KE-Cap-NTC flow3xBOOST 0 SiC 1200 20 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Triple Boost-KE-Cap-NTC
flow3xBOOST 0 SIC
10-FZ06NRA041FS03-P965F78 Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 MOS 1200 30 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 MOS
V23990-P543-D28-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 600 10 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-PZ123BA080MR-M909L28Y Series production Booster Triple Boost-KE-Cap-NTC flow3xBOOST 0 SiC 1200 20 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Triple Boost-KE-Cap-NTC
flow3xBOOST 0 SIC
10-FZ122PB075SC-M818F08 Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 75 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-F012NME080SH-M910F09 Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 IGBT4 HS flow 0 17 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
10-F007NRA050SG-P966F09 Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 IGBT 1200 50 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 IGBT
10-FZ126PA035M7-P860F78 Series production Sixpack Inverter-KE-NTC flowPACK 0 1200 35 IGBT M7 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
10-FZ12NMA080SH04-M260F13 Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
10-FZ126PA025M7-P869F78 Series production Sixpack Inverter-KE-NTC flowPACK 0 1200 25 IGBT M7 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
10-PZ12NMA080SH04-M260F13Y Series production Three-level MNPC (T-Type) MNPC (T-type)-KE-NTC flowMNPC 0 1200 80 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-NTC
flowMNPC 0
10-PZ06NRA041FS03-P965F78Y Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 MOS 1200 30 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 MOS
10-FZ126PA015M7-P868F78 Series production Sixpack Inverter-KE-NTC flowPACK 0 1200 15 IGBT M7 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
10-FZ126PA010M7-P867F78 Series production Sixpack Inverter-KE-NTC flowPACK 0 1200 10 IGBT M7 flow 0 12 Al2O3 Module datasheet:PDF
Inverter-KE-NTC
flowPACK 0
V23990-P629-L63-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ122PB100SC02-M819F08 Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
V23990-P629-L43-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 50 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ122PB100SC03-M819F18 Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 flow 0 12 AlN Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-FZ122PB100SH-M819F28 Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-FZ07BVA020SM-LD44E08 In qualification H6.5 Booster + H6.5-KE-NTC flowSOL 0 BI (TL) 650 20 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Booster + H6.5-KE-NTC
flowSOL 0 BI (TL)
10-F0122PB100SC02-M819F09 Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-F0122PB100SC03-M819F19 Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 flow 0 17 AlN Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-PZ122PB100SH-M819F28Y Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-PZ122PB100SH01-M819F38Y Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 HS flow 0 12 AlN Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-FZ12PMA005M7-P848A28 Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 5 IGBT M7 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ12PMA010M7-P849A28 Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 10 IGBT M7 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ12PMA015M7-P840A28 Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 15 IGBT M7 flow 0 12 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-PZ122PB100SC02-M819F08Y Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-F012PMA005M7-P848A29 Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 5 IGBT M7 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
V23990-P629-L99-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 17 AlN Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-PZ122PB100SC03-M819F18Y Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 flow 0 12 AlN Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-F012PMA010M7-P849A29 Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 10 IGBT M7 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ122PB050SC02-M817F08 Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 50 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-F012PMA015M7-P840A29 Series production PIM (CIB) CIB-OE-NTC flowPIM® 0 1200 15 IGBT M7 flow 0 17 Al2O3 Module datasheet:PDF
CIB-OE-NTC
flowPIM 0
10-FZ07NIA050SM-P925F58 In qualification Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 1200 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0
10-FX062TA099FS-P980D57 Series production PFC (Single-phase applications) Dual Boost PFC-Half Controlled-Shunt-Cap-NTC flowPFC 0 600 36 Infineon CoolMOS™ C6 flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost PFC-Half Controlled-Shunt-Cap-NTC
flowPFC 0
10-FZ06NPA070FP-P969F Series production Three-level NPC (I-Type) NPC-KE-Parallel-NTC flowNPC 0 parallel 1200 75 Parallel Switch flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-Parallel-NTC
flowNPC 0 parallel
V23990-P629-L48Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ07NBA100SM10-M305L68 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 symmetric 650 100 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 symmetric
10-PC124PA040MR-L638F18Y Series production H-Bridge 2xHalf Bridge-KE-NTC fastPACK 0 SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
2xHalf Bridge-KE-NTC
fastPACK 0 SiC
10-PZ12NMA027MR-M340F68Y In qualification Three-level MNPC (T-Type) MNPC (T-type)-KE-Split Output-Cap-NTC-Common Emitter flowMNPC 0 SiC 1200 100 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-Split Output-Cap-NTC-Common Emitter
flowMNPC 0 SIC
10-PZ12NMA027ME-M340F63Y In qualification Three-level MNPC (T-Type) MNPC (T-type)-KE-Split Output-Cap-NTC-Common Emitter flowMNPC 0 SiC 1200 100 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
MNPC (T-type)-KE-Split Output-Cap-NTC-Common Emitter
flowMNPC 0 SIC
10-PZ074PA030SM-L623F08Y Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 0 H C 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 0 H C
V23990-P623-L82-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-PZ074PA050SM-L624F08Y Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 0 H C 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 0 H C
10-PZ074PA075SM-L625F08Y Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 0 H C 650 75 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 0 H C
V23990-P623-F59-PM In qualification H-Bridge H-Bridge-KE-NTC fastPACK 0 H 650 50 IGBT H5 flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
10-FZ06NRA041FS02-P965F68 Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 MOS 1200 30 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 MOS
V23990-P849-C48-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 8 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
10-PZ06NRA041FS02-P965F68Y Series production Three-level NPC (I-Type) NPC-KE-NTC flowNPC 0 MOS 1200 30 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
NPC-KE-NTC
flowNPC 0 MOS
V23990-P848-C49-PM Series production PIM (CIB) CI-OE-NTC flowPIM® 0 1200 4 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
CI-OE-NTC
flowPIM 0
V23990-P640-G08Y-PM In qualification Rectifier (+Brake) 3ph-Rectifier-BRC flowCON 0 1600 75 Rectifier flow 0 12 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC
flowCON 0
V23990-P629-L48-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-F0127PA025SC-L159E09 In qualification Sevenpack IB-OE-NTC flow7PACK 0 1200 25 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
IB-OE-NTC
flow7PACK 0
10-PZ12B2A040ME01-M330L63Y In qualification Booster Dual Boost-KE-Cap-NTC flowBOOST 0 dual SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-Cap-NTC
flowBOOST 0 dual SIC
10-PZ06NRA084FP02-P969F68Y Series production Three-level NPC (I-Type)
