Part-No Product status Topology Sub-Topology Product line Voltage

in V
Current

in A
Main Chip technology Housing family Height in

mm
Isolation Module datasheet
10-FZ071SA050SM02-L524L18 Series production PFC (Three-phase applications) SPFC-KE-Cap-NTC flowSPFC 0 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
SPFC-KE-Cap-NTC
flowSPFC 0
10-FZ071SA075SM02-L525L18 Series production PFC (Three-phase applications) SPFC-KE-Cap-NTC flowSPFC 0 650 75 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
SPFC-KE-Cap-NTC
flowSPFC 0
V23990-P623-F04-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 600 60 IGBT2 HS flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
10-FZ071SA100SM02-L526L18 Series production PFC (Three-phase applications) SPFC-KE-Cap-NTC flowSPFC 0 650 100 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
SPFC-KE-Cap-NTC
flowSPFC 0
V23990-P623-F14-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 600 60 IGBT2 HS flow 0 17 AlN Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
10-F0062TA030FB05-P983D59 Series production PFC (Single-phase applications) Dual Boost PFC-CSC-Shunt-Cap-NTC flowPFC 0 600 30 IGBT2 HS flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost PFC-CSC-Shunt-Cap-NTC
flowPFC 0
V23990-P623-F24-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 600 50 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
10-F0062TA030FB06-P983D79 Series production PFC (Single-phase applications) Dual Boost PFC-CSC-Shunt-Cap-NTC flowPFC 0 600 30 IGBT2 HS flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost PFC-CSC-Shunt-Cap-NTC
flowPFC 0
V23990-P625-F24-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 600 100 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
V23990-P624-F24-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 600 75 IGBT3 flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
V23990-P729-F48-PM Series production H-Bridge H-Bridge-KE-Cap-NTC fastPACK 0 H C 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-Cap-NTC
fastPACK 0 H C
V23990-P629-F48-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
V23990-P718-G-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flow90CON 1 1600 52 Rectifier flow 90 1 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flow90CON 1
V23990-P718-G10-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flow90CON 1 1600 43 Thyristor (SCR) flow 90 1 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flow90CON 1
V23990-P719-G-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flow90CON 1 1600 75 Rectifier flow 90 1 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flow90CON 1
V23990-P629-L99Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 17 AlN Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
V23990-P629-L58-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
V23990-P629-L58Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-PC094PB017ME02-L620F36Y In qualification H-Bridge H-Bridge-OE-KE-Cap-NTC fastPACK 0 SiC 900 80 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-OE-KE-Cap-NTC
fastPACK 0 SiC
V23990-P723-F04-PM Series production H-Bridge H-Bridge-KE-Cap-NTC fastPACK 0 H C 600 60 IGBT2 HS flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-Cap-NTC
fastPACK 0 H C
10-FZ07BIA030S5Y-P894E78 Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT S5 flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
V23990-P729-F44-PM Series production H-Bridge H-Bridge-KE-Cap-NTC fastPACK 0 H C 1200 25 IGBT2 flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-Cap-NTC
fastPACK 0 H C
30-F2166BA150RW-L267G09 Series production Rectifier (+Brake) 3ph-Rectifier-BRC flowCON 2 1600 150 Rectifier flow 2 17 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC
flowCON 2
V23990-P729-F46-PM Series production H-Bridge H-Bridge-KE-Cap-NTC fastPACK 0 H C 1200 25 IGBT2 flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-Cap-NTC
fastPACK 0 H C
A0-VP122PA300M7-L757F70T In qualification Half-Bridge Half Bridge-NTC VINcoDUAL E3 1200 300 IGBT M7 VINco E3s 17 IMB Module datasheet:PDF
Half Bridge-NTC
VINcoDUAL E3
V23990-P729-F54-PM Series production H-Bridge H-Bridge-KE-Cap-NTC fastPACK 0 H C 1200 25 IGBT2 flow 0 17 AlN Module datasheet:PDF
H-Bridge-KE-Cap-NTC
fastPACK 0 H C
V23990-P729-F49-PM Series production H-Bridge H-Bridge-KE-Cap-NTC fastPACK 0 H C 1200 40 IGBT4 HS flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-Cap-NTC
fastPACK 0 H C
V23990-P729-F56-PM Series production H-Bridge H-Bridge-KE-Cap-NTC fastPACK 0 H C 1200 25 IGBT2 flow 0 17 AlN Module datasheet:PDF
H-Bridge-KE-Cap-NTC
fastPACK 0 H C
V23990-P627-F88-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 1200 15 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
V23990-P717-G10-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flow90CON 1 1600 36 Thyristor (SCR) flow 90 1 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flow90CON 1
V23990-P717-H-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flow90CON 1 1600 39 Rectifier flow 90 1 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flow90CON 1
V23990-P717-H10-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flow90CON 1 1600 36 Thyristor (SCR) flow 90 1 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flow90CON 1
V23990-P718-H-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flow90CON 1 1600 52 Rectifier flow 90 1 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flow90CON 1
V23990-P718-H10-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flow90CON 1 1600 43 Thyristor (SCR) flow 90 1 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flow90CON 1
V23990-P629-L49Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
V23990-P719-H-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flow90CON 1 1600 75 Rectifier flow 90 1 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flow90CON 1
10-TY12NMB030SM-L394L08 In qualification PFC (Three-phase applications) 3xNPFC-NTC flow3xNPFC 1 650 30 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
3xNPFC-NTC
flow3xNPFC 1
10-PZ07BIA030SG-P894E38Y Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT3 HS flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
V23990-P640-G-PM Series production Rectifier (+Brake) 3ph-Rectifier-BRC flowCON 0 1600 75 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC
flowCON 0
V23990-P627-F89-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 1200 15 IGBT4 HS flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
10-PZ07BIA030RW-P894E88Y Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT fast flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
V23990-P640-H-PM Series production Rectifier (+Brake) 3ph-Rectifier flowCON 0 1600 75 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Rectifier
flowCON 0
10-FZ07BIA030SG-P894E38 Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT3 HS flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
V23990-P649-G-PM Series production Rectifier (+Brake) 3ph-Rectifier-BRC flowCON 0 1600 50 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC
flowCON 0
10-FZ07BIA030RW-P894E88 Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT fast flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
V23990-P649-H-PM Series production Rectifier (+Brake) 3ph-Rectifier flowCON 0 1600 50 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Rectifier
flowCON 0
10-F0062TA099FS-P980D59 Series production PFC (Single-phase applications) Dual Boost PFC-Half Controlled-Shunt-Cap-NTC flowPFC 0 600 18 Infineon CoolMOS™ C6 flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost PFC-Half Controlled-Shunt-Cap-NTC
flowPFC 0
V23990-P590-J19-PM Series production Rectifier (+Brake) 1ph-Half Controlled flowCON 0 1600 75 Thyristor (SCR) flow 0 17 Al2O3 Module datasheet:PDF
1ph-Half Controlled
flowCON 0
10-FZ07BIA030SM01-P894E68 Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
V23990-P600-I19-PM Series production Rectifier (+Brake) Modular Half Controlled-BRC flowCON 0 1600 75 Thyristor (SCR) flow 0 17 Al2O3 Module datasheet:PDF
Modular Half Controlled-BRC
flowCON 0
V23990-P640-G10-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flowCON 0 1600 42 Thyristor (SCR) flow 0 17 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flowCON 0
10-FY12B2A040MR-L387L68 Series production Booster Dual Boost-KE-Cap-Bypass diode-NTC flowBOOST 1 dual SiC 1200 35 SiC MOSFET flow 1 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-Cap-Bypass diode-NTC
flowBOOST 1 dual SiC
V23990-P640-H10-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flowCON 0 1600 42 Thyristor (SCR) flow 0 17 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flowCON 0
V23990-P649-G10-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flowCON 0 1600 34 Thyristor (SCR) flow 0 17 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flowCON 0
V23990-P649-H10-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flowCON 0 1600 34 Thyristor (SCR) flow 0 17 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flowCON 0
10-FZ07NBA075SM-P916L58 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 symmetric 650 75 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 symmetric
V23990-P623-F58-PM Series production H-Bridge H-Bridge-KE-NTC fastPACK 0 H 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
V23990-P590-J09-PM Series production Rectifier (+Brake) 1ph-Rectifier flowCON 0 1600 105 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
1ph-Rectifier
flowCON 0
V23990-P600-I09-PM Series production Rectifier (+Brake) Modular Rectifier-BRC flowCON 0 1600 105 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
Modular Rectifier-BRC
flowCON 0
V23990-P629-F62-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 1200 40 NPT IGBT flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0
V23990-P629-F628Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 1200 40 NPT IGBT flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0
V23990-P629-F629-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 1200 40 NPT IGBT flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0
V23990-P629-L98-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 1200 40 NPT IGBT flow 0 12 AlN Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0
10-FZ062TA099FS05-P980D68 Series production PFC (Single-phase applications) Dual Boost PFC-CSC-Shunt-Cap-NTC flowPFC 0 CD 600 18 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost PFC-CSC-Shunt-Cap-NTC
flowPFC 0 CD
10-FY07ZAA015SM-L512B28 In qualification Single-phase Inverter Rectifier + Dual Booster + H-Bridge-KE-OE-NTC-CAP flowRPI 1 650 15 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
Rectifier + Dual Booster + H-Bridge-KE-OE-NTC-CAP
flowRPI 1
10-FY07ZAA030SM-L513B28 In qualification Single-phase Inverter Rectifier + Dual Booster + H-Bridge-KE-OE-NTC-CAP flowRPI 1 650 30 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
Rectifier + Dual Booster + H-Bridge-KE-OE-NTC-CAP
flowRPI 1
30-F2166BA150RW01-L267G19 Series production Rectifier (+Brake) 3ph-Rectifier-BRC-NTC flowCON 2 1600 150 IGBT4 flow 2 17 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC-NTC
flowCON 2
10-FY07ZAA050SM-L514B28 In qualification Single-phase Inverter Rectifier + Dual Booster + H-Bridge-KE-OE-NTC-CAP flowRPI 1 650 50 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
Rectifier + Dual Booster + H-Bridge-KE-OE-NTC-CAP
flowRPI 1
10-FY074PA100SM-L583F08 Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 1 H C 650 100 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 1 H C
10-FY124PA040FV-L588F88 In qualification H-Bridge H-Bridge-KE-OE-NTC flowPACK 1 H 1200 40 Trench Field Stop IGBT flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-NTC
flowPACK 1 H
10-PY124PA040FV-L588F88Y In qualification H-Bridge H-Bridge-KE-OE-NTC flowPACK 1 H 1200 40 Trench Field Stop IGBT flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-NTC
flowPACK 1 H
10-FY124PA040SH-L588F48 In qualification H-Bridge H-Bridge-KE-OE-NTC flowPACK 1 H 1200 40 IGBT4 HS flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-NTC
flowPACK 1 H
10-FZ06BIA083FI-P896E Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (T) primary 600 30 Infineon CoolMOS™ CFD2 flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (T) primary
10-PY124PA040SH-L588F48Y In qualification H-Bridge H-Bridge-KE-OE-NTC flowPACK 1 H 1200 40 IGBT4 HS flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-NTC
flowPACK 1 H
10-FY124PA080FV-L589F88 In qualification H-Bridge H-Bridge-KE-OE-NTC flowPACK 1 H 1200 80 Trench Field Stop IGBT flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-NTC
flowPACK 1 H
10-PY124PA080FV-L589F88Y In qualification H-Bridge H-Bridge-KE-OE-NTC flowPACK 1 H 1200 80 Trench Field Stop IGBT flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-NTC
flowPACK 1 H
10-FY124PA080SH-L589F48 In qualification H-Bridge H-Bridge-KE-OE-NTC flowPACK 1 H 1200 80 IGBT4 HS flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-NTC
flowPACK 1 H
10-PY124PA080SH-L589F48Y In qualification H-Bridge H-Bridge-KE-OE-NTC flowPACK 1 H 1200 80 IGBT4 HS flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-NTC
flowPACK 1 H
V23990-P629-L63Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-P0166BA050RW-LD59G09Y Series production Rectifier (+Brake) 3ph-Non Controlled-BRC-KE-NTC flowCON 0 1600 50 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Non Controlled-BRC-KE-NTC
flowCON 0
10-FY07BIA050SM-M523E38 Series production Single-phase Inverter Dual Booster + H-Bridge-KE-Cap-NTC-bypass diode flowSOL 1 BI (TL) 650 50 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
Dual Booster  + H-Bridge-KE-Cap-NTC-bypass diode
flowSOL 1 BI (TL)
10-PD166BA050RW-LD59G07Y Series production Rectifier (+Brake) 3ph-Non Controlled-BRC-KE-NTC flowCON 0 1600 50 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Non Controlled-BRC-KE-NTC
flowCON 0
10-FZ062TA030SM-P986D13 In qualification PFC (Single-phase applications) Dual Boost PFC-CSC-Shunt-Cap-NTC flowPFC 0 CD 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost PFC-CSC-Shunt-Cap-NTC
flowPFC 0 CD
10-PY07BIA050SM-M523E38Y Series production Single-phase Inverter Dual Booster + H-Bridge-KE-Cap-NTC-bypass diode flowSOL 1 BI (TL) 650 50 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
Dual Booster  + H-Bridge-KE-Cap-NTC-bypass diode
flowSOL 1 BI (TL)
10-FZ062TA050SM-P987D13 In qualification PFC (Single-phase applications) Dual Boost PFC-CSC-Shunt-Cap-NTC flowPFC 0 CD 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost PFC-CSC-Shunt-Cap-NTC
flowPFC 0 CD
V23990-P621-F68Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 900 19 Infineon CoolMOS™ C3 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FY074PA040CR-L581F78 In qualification H-Bridge H-Bridge-OE-KE-Cap-NTC fastPACK 1 MOS 650 40 Infineon CoolMOS™ CFD2 flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-OE-KE-Cap-NTC
fastPACK 1 MOS
10-PY074PA040CR-L581F78Y In qualification H-Bridge H-Bridge-OE-KE-Cap-NTC fastPACK 1 MOS 650 40 Infineon CoolMOS™ CFD2 flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-OE-KE-Cap-NTC
fastPACK 1 MOS
10-FY074PA020CR-L582F78 In qualification H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 1 MOS 650 80 Infineon CoolMOS™ CFD2 flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 1 MOS
10-PY074PA020CR-L582F78Y In qualification H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 1 MOS 650 80 Infineon CoolMOS™ CFD2 flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 1 MOS
10-FZ062TA099FH01-P980D28 Series production PFC (Single-phase applications) Dual Boost PFC-Half Controlled-CSE-Shunt-Cap-NTC flowPFC 0 CD 600 30 Infineon CoolMOS™ CP flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost PFC-Half Controlled-CSE-Shunt-Cap-NTC
flowPFC 0 CD
10-PC094PB065ME01-L637F06Y Series production H-Bridge 2xHalf Bridge-KE-NTC fastPACK 0 SiC 900 20 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
2xHalf Bridge-KE-NTC
fastPACK 0 SiC
10-FY074PA100SM01-L583F18 In qualification H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 1 H C 650 100 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 1 H C
10-FZ07LBA100SM03-L705L08 In qualification PFC (Three-phase applications) NPFC-Cap-NTC flowNPFC 0 650 100 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
NPFC-Cap-NTC
flowNPFC 0
10-FZ07NBA030SM01-P914L53 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 s+b 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 s+b
10-FY07NBA075S5-M505L58 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 1 symmetric 650 75 IGBT S5 flow 1 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 1 symmetric
10-FZ074PA030SM-L623F08 Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 0 H C 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 0 H C
10-FZ062TA040FB-P984D18 Series production PFC (Single-phase applications) Dual Boost PFC-CSC-Shunt-Cap-NTC flowPFC 0 CD 600 50 IGBT2 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost PFC-CSC-Shunt-Cap-NTC
flowPFC 0 CD
10-FZ074PA050SM-L624F08 Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 0 H C 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 0 H C
10-FZ07B2A030SM02-M575L48 Series production Booster Dual Boost-KE-Cap-NTC flow2xBOOST 0 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-Cap-NTC
flow2xBOOST 0
10-FZ074PA075SM-L625F08 Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 0 H C 650 75 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 0 H C
80-M3166BA125AS02-K849G32 Series production Rectifier (+Brake) 3ph-Full Controlled-BRC-NTC MiniSKiiP® CON 3 1600 125 Thyristor (SCR) MiniSKiiP® 3 16 Al2O3 Module datasheet:PDF
3ph-Full Controlled-BRC-NTC
MiniSKiiP CON 3
10-F106BIB020FK-M285L Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 1 symmetric 600 80 ST MDmesh™ M5 flow 1 17 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 1 symmetric
10-PZ06O2A030FW-LH02J08Y Series production Ultrafast Rectifier 1ph-Non-Controlled–NTC flowCON 0 600 30 Fast diode flow 0 12 Al2O3 Module datasheet:PDF
1ph-Non-Controlled–NTC
flowCON 0
10-FZ06NBA084FP10-M306L38 Series production Booster Symmetric Symm. Boost-KE-Parallel-NTC flowBOOST 0 600 84 Trench Field Stop IGBT flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Parallel-NTC
flowBOOST 0
10-FZ07LBA100SM01-L705L18 Series production PFC (Three-phase applications) NPFC-Cap-NTC flowNPFC 0 650 100 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
NPFC-Cap-NTC
flowNPFC 0
10-FZ07NBA075SG10-M304L58 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 650 75 Trench Field Stop IGBT flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0
V23990-P629-L43Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 50 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
V23990-P640-G20-PM Series production Rectifier (+Brake) 3ph-Rectifier-BRC flowCON 0 1600 75 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC
flowCON 0
10-FZ074PA080CR-L622F68 Series production H-Bridge H-Bridge-OE-KE-Cap-NTC fastPACK 0 MOS 650 20 Infineon CoolMOS™ CFD2 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-OE-KE-Cap-NTC
fastPACK 0 MOS
80-M3166BB125AS-K489G31 Series production Rectifier (+Brake) 3ph-Half Controlled-BRC-NTC MiniSKiiP® CON 3 1200 125 Thyristor (SCR) MiniSKiiP® 3 16 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC-NTC
MiniSKiiP CON 3
10-PZ074PA080CR-L622F68Y Series production H-Bridge H-Bridge-OE-KE-Cap-NTC fastPACK 0 MOS 650 20 Infineon CoolMOS™ CFD2 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-OE-KE-Cap-NTC
fastPACK 0 MOS
10-PZ07NBA100SM10-M305L68Y Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 symmetric 650 100 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 symmetric
30-F206NBA200SG-M235L33 Series production Booster Symmetric Symm. Boost-KE-Bypass diode-NTC flowBOOST 2 600 200 IGBT3 flow 2 17 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Bypass diode-NTC
flowBOOST 2
10-PZ06NBA041FS-P915L68Y Series production Booster Symmetric Symm. Boost-KE-Bypass diode-NTC flowBOOST 0 s+b 600 40 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Bypass diode-NTC
flowBOOST 0 s+b
10-FZ06NBA041FS01-P915L78 Series production Booster Symmetric Symm. Boost-KE-Bypass diode-NTC flowBOOST 0 s+b 600 40 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Bypass diode-NTC
flowBOOST 0 s+b
A0-VS122PA690M7-L750F70 In qualification Half-Bridge Half Bridge-NTC VINcoDUAL E3 1200 690 IGBT M7 VINco E3s 17 IMB Module datasheet:PDF
Half Bridge-NTC
VINcoDUAL E3
V23990-P717-G-PM Series production Rectifier (+Brake) 3ph-Half Controlled-BRC flow90CON 1 1600 39 Rectifier flow 90 1 Al2O3 Module datasheet:PDF
3ph-Half Controlled-BRC
flow90CON 1
V23990-P629-F63-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
V23990-P629-F72-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
30-FT123BA040MR-L878L08 In qualification Booster Triple Boost-KE-Cap-Bypass diode-NTC flow3xBOOST 2 SiC 1200 35 SiC MOSFET flow 2 13 Al2O3 Module datasheet:PDF
Triple Boost-KE-Cap-Bypass diode-NTC
flow3xBOOST 2 SIC
10-PZ123BA040MR01-M909L68Y In qualification Booster Triple Boost-KE-Cap-NTC flow3xBOOST 0 SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Triple Boost-KE-Cap-NTC
flow3xBOOST 0 SIC
10-FZ071SA075S501-L525L58 Series production PFC (Three-phase applications) SPFC-KE-NTC flowSPFC 0 650 75 IGBT S5 flow 0 12 Al2O3 Module datasheet:PDF
SPFC-KE-NTC
flowSPFC 0
10-FY07NBA100S5-M506L58 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 1 symmetric 650 100 IGBT S5 flow 1 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 1 symmetric
A0-VS122PA600M7-L759F70 In qualification Half-Bridge Half Bridge-NTC VINcoDUAL E3 1200 600 IGBT M7 VINco E3s 17 IMB Module datasheet:PDF
Half Bridge-NTC
VINcoDUAL E3
10-FY12B2A040MR02-L387L63 In qualification Booster Dual Boost-KE-Cap-Bypass diode-NTC flowBOOST 1 dual SiC 1200 35 SiC MOSFET flow 1 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-Cap-Bypass diode-NTC
flowBOOST 1 dual SiC
A0-VS122PA450M7-L758F70 In qualification Half-Bridge Half Bridge-NTC VINcoDUAL E3 1200 450 IGBT M7 VINco E3s 17 IMB Module datasheet:PDF
Half Bridge-NTC
VINcoDUAL E3
A0-VS122PA300M7-L757F70 In qualification Half-Bridge Half Bridge-NTC VINcoDUAL E3 1200 300 IGBT M7 VINco E3s 17 IMB Module datasheet:PDF
Half Bridge-NTC
VINcoDUAL E3
80-M2166RA075RS-K738H Series production Rectifier (+Brake) 3ph Rectifier-NTC MiniSKiiP® CON 2 1600 75 Rectifier MiniSKiiP® 2 16 Al2O3 Module datasheet:PDF
3ph Rectifier-NTC
MiniSKiiP CON 2
80-M2166RA075RS-K738H10 Series production Rectifier (+Brake) 3ph Rectifier-NTC MiniSKiiP® CON 2 1600 75 Rectifier MiniSKiiP® 2 16 Al2O3 Module datasheet:PDF
3ph Rectifier-NTC
MiniSKiiP CON 2
10-FY07NBA150S5-M506L98 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 1 symmetric 650 150 IGBT S5 flow 1 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 1 symmetric
10-FZ06NBA110FP-M306L28 In qualification Booster Symmetric Symm. Boost-KE-Parallel-NTC flowBOOST 0 symmetric 600 110 Parallel Switch flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Parallel-NTC
flowBOOST 0 symmetric
V23990-P640-H09-PM In qualification Rectifier (+Brake) 3ph-Rectifier flowCON 0 1600 75 Rectifier flow 0 17 Al2O3 Module datasheet:PDF
3ph-Rectifier
flowCON 0
10-FY07ZAB050SM-L514B08 In qualification Single-phase Inverter Rectifier + Dual Booster + H-Bridge-KE-OE-NTC-CAP flowRPI 1 650 50 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
Rectifier + Dual Booster + H-Bridge-KE-OE-NTC-CAP
flowRPI 1
10-FY07ZAB075SM-L515B08 In qualification Single-phase Inverter Rectifier + Dual Booster + H-Bridge-KE-OE-NTC-CAP flowRPI 1 650 75 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
Rectifier + Dual Booster + H-Bridge-KE-OE-NTC-CAP
flowRPI 1
A0-VP122PA450M7-L758F70T In qualification Half-Bridge Half Bridge-NTC VINcoDUAL E3 1200 450 IGBT M7 VINco E3s 17 IMB Module datasheet:PDF
Half Bridge-NTC
VINcoDUAL E3
A0-VP122PA600M7-L759F70T In qualification Half-Bridge Half Bridge-NTC VINcoDUAL E3 1200 600 IGBT M7 VINco E3s 17 IMB Module datasheet:PDF
Half Bridge-NTC
VINcoDUAL E3
A0-VP122PA690M7-L750F70T In qualification Half-Bridge Half Bridge-NTC VINcoDUAL E3 1200 690 IGBT M7 VINco E3s 17 IMB Module datasheet:PDF
Half Bridge-NTC
VINcoDUAL E3
V23990-P629-F73-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FY064PA050SG10-M582F08 Series production H-Bridge H-Bridge-KE-OE-NTC flowPACK 1 H 600 50 IGBT3 HS flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-NTC
flowPACK 1 H
80-M2072PA150SA-K704F30 Series production Half-Bridge Half Bridge-NTC MiniSKiiP® DUAL 2 650 150 IGBT3 MiniSKiiP® DUAL 2 16 Al2O3 Module datasheet:PDF
Half Bridge-NTC
MiniSKiip DUAL 2
10-PC094PB035ME02-L629F36Y In qualification H-Bridge H-Bridge-OE-KE-Cap-NTC fastPACK 0 SiC 900 40 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-OE-KE-Cap-NTC
fastPACK 0 SiC
80-M2072PA200SA-K705F30 Series production Half-Bridge Half Bridge-NTC MiniSKiiP® DUAL 2 650 200 IGBT3 MiniSKiiP® DUAL 2 16 Al2O3 Module datasheet:PDF
Half Bridge-NTC
MiniSKiip DUAL 2
10-FZ06NBA084FP-M306L48 In qualification Booster Symmetric Symm. Boost-KE-Parallel-NTC flowBOOST 0 symmetric 600 84 Parallel Switch flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Parallel-NTC
flowBOOST 0 symmetric
10-FZ06NBA075SA-P916L33 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 s+b 600 75 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 s+b
80-M3122PA300SC-K839F42 Series production Half-Bridge Half Bridge-NTC MiniSKiiP® DUAL 3 1200 300 IGBT4 MiniSKiiP® DUAL 3 16 Al2O3 Module datasheet:PDF
Half Bridge-NTC
MiniSKiip DUAL 3
10-FY07BIA041MF-M528E68 Series production Single-phase Inverter Dual Booster + H-Bridge-KE-Cap-NTC flowSOL 1 BI (TL) 650 33 Infineon CoolMOS™ CFD2 flow 1 12 Al2O3 Module datasheet:PDF
Dual Booster  + H-Bridge-KE-Cap-NTC
flowSOL 1 BI (TL)
V23990-P621-F68-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 900 19 Infineon CoolMOS™ C3 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
80-M3072PA300SA-K836F30 Series production Half-Bridge Half Bridge-NTC MiniSKiiP® DUAL 3 650 300 IGBT3 MiniSKiiP® DUAL 3 16 Al2O3 Module datasheet:PDF
Half Bridge-NTC
MiniSKiip DUAL 3
10-FZ06NBA030SA-P914L33 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 s+b 600 30 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 s+b
10-FZ06NBA050SA-P915L33 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 s+b 600 50 IGBT3 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 s+b
80-M2122PA150SC-K708F40 Series production Half-Bridge Half Bridge-NTC MiniSKiiP® DUAL 2 1200 150 IGBT4 MiniSKiiP® DUAL 2 16 Al2O3 Module datasheet:PDF
Half Bridge-NTC
MiniSKiip DUAL 2
V23990-P629-L59-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
V23990-P629-L49-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ063BA040MF-M575L08 Series production Booster Triple Boost-KE-Cap-NTC flow3xBOOST 0 600 44 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
Triple Boost-KE-Cap-NTC
flow3xBOOST 0
10-FZ06B2A040MF01-M575L28 Series production Booster Triple Boost-KE-Cap-NTC flow2xBOOST 0 600 40 Infineon CoolMOS™ C6 flow 0 12 Al2O3 Module datasheet:PDF
Triple Boost-KE-Cap-NTC
flow2xBOOST 0
10-PZ12B2A040MR01-M330L68Y In qualification Booster Dual Boost-KE-Cap-NTC flowBOOST 0 SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-Cap-NTC
flowBOOST 0 SIC
V23990-P629-L83-PM In qualification Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 SIC
10-FY074PA075SG-M583F08 Series production H-Bridge H-Bridge-KE-OE-NTC flowPACK 1 H 650 75 IGBT3 HS flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-NTC
flowPACK 1 H
10-FZ073BA030SM02-M575L38 Series production Booster Triple Boost-KE-Cap-NTC flow3xBOOST 0 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Triple Boost-KE-Cap-NTC
flow3xBOOST 0
10-FY07BIA041MC-M528E58 Series production Single-phase Inverter Dual Booster + H-Bridge-KE-Cap-NTC flowSOL 1 BI (TL) 650 33 Infineon CoolMOS™ CFD2 flow 1 12 Al2O3 Module datasheet:PDF
Dual Booster  + H-Bridge-KE-Cap-NTC
flowSOL 1 BI (TL)
80-M2122PA200SC-K709F40 Series production Half-Bridge Half Bridge-NTC MiniSKiiP® DUAL 2 1200 200 IGBT4 MiniSKiiP® DUAL 2 16 Al2O3 Module datasheet:PDF
Half Bridge-NTC
MiniSKiip DUAL 2
V23990-P629-L81-PM In qualification Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 SIC
80-M3122PA400SC-K830F40 Series production Half-Bridge Half Bridge-NTC MiniSKiiP® DUAL 3 1200 400 IGBT4 MiniSKiiP® DUAL 3 16 Al2O3 Module datasheet:PDF
Half Bridge-NTC
MiniSKiip DUAL 3
V23990-P629-L94-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 17 AlN Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ07NBA050SM-P915L58 In qualification Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 s+b 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 s+b
10-FY07NBA100SM-M506L48 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 1 symmetric 650 100 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 1 symmetric
10-FY06BIA080MF-M527E58 Series production Single-phase Inverter Dual Booster + H-Bridge-KE-NTC-CAP flowSOL 1 BI (T) primary 650 20 Infineon CoolMOS™ CFD2 flow 1 12 Al2O3 Module datasheet:PDF
Dual Booster  + H-Bridge-KE-NTC-CAP
flowSOL 1 BI (T) primary
V23990-P629-L94Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 17 AlN Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
30-F206NBA200SG-M235L25 Series production Booster Symmetric Symm. Boost-KE-Bypass diode-NTC flowBOOST 2 symmetric 600 200 IGBT3 HS flow 2 17 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Bypass diode-NTC
flowBOOST 2 symmetric
80-M2122PA200M7-K709F70 Series production Half-Bridge Half Bridge-NTC MiniSKiiP® DUAL 2 1200 200 IGBT M7 MiniSKiiP® DUAL 2 16 Al2O3 Module datasheet:PDF
Half Bridge-NTC
MiniSKiip DUAL 2
10-PZ123BA080ME-M909L18Y Series production Booster Triple Boost-KE-Cap-NTC flow3xBOOST 0 SiC 1200 20 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Triple Boost-KE-Cap-NTC
flow3xBOOST 0 SIC
10-PZ123BA080MR-M909L28Y Series production Booster Triple Boost-KE-Cap-NTC flow3xBOOST 0 SiC 1200 20 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Triple Boost-KE-Cap-NTC
flow3xBOOST 0 SIC
10-FZ122PB075SC-M818F08 Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 75 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
70-W206NBA600SA-M788L Series production Booster Symmetric Symm. Boost-KE-Cap-NTC VINcoBOOST X4 symmetric 600 600 IGBT3 VINco X4 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Cap-NTC
VINcoBOOST X4 symmetric
10-FY06BIA050SG-M523E18 Series production Single-phase Inverter Dual Booster + H-Bridge-KE-Cap-NTC-bypass diode flowSOL 1 BI (TL) 600 50 IGBT3 HS flow 1 12 Al2O3 Module datasheet:PDF
Dual Booster  + H-Bridge-KE-Cap-NTC-bypass diode
flowSOL 1 BI (TL)
V23990-P629-L63-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ122PB100SC02-M819F08 In qualification Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
V23990-P629-L43-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 50 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ122PB100SC03-M819F18 Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 flow 0 12 AlN Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-0B166BA028SC-M989G09 In qualification Rectifier (+Brake) 3ph-Rectifier-BRC flowCON 0B 1600 35 Rectifier flow 0B 17 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC
flowCON 0B
10-FZ122PB100SH-M819F28 Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
V23990-P629-F629Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 1200 40 NPT IGBT flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0
10-PY074PA100SM01-L583F18Y In qualification H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 1 H C 650 100 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 1 H C
10-FY09S2A065ME-L869L08 Series production Booster Symmetric Dual Symm. Boost-KE-Bypass diode-NTC flowBOOST 1 symmetric 900 50 SiC MOSFET flow 1 12 Al2O3 Module datasheet:PDF
Dual Symm. Boost-KE-Bypass diode-NTC
flowBOOST 1 symmetric
10-FY07NBA160RV-M506L78 In qualification Booster Symmetric Symm. Boost-KE-NTC flowBOOST 1 symmetric 650 160 IGBT fast flow 1 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 1 symmetric
10-F0122PB100SC02-M819F09 In qualification Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 flow 0 17 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-F0122PB100SC03-M819F19 Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 flow 0 17 AlN Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-PZ122PB100SH-M819F28Y In qualification Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-PZ122PB100SH01-M819F38Y In qualification Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 HS flow 0 12 AlN Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-PZ122PB100SC02-M819F08Y In qualification Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
V23990-P629-L99-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 NPT IGBT flow 0 17 AlN Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-PZ122PB100SC03-M819F18Y Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 100 IGBT4 flow 0 12 AlN Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
10-FZ122PB050SC02-M817F08 Series production Half-Bridge Half Bridge-NTC flowPHASE 0 + NTC 1200 50 IGBT4 flow 0 12 Al2O3 Module datasheet:PDF
Half Bridge-NTC
flowPHASE 0 + NTC
70-W206NBA400SA-M786L Series production Booster Symmetric Symm. Boost-KE-Cap-NTC VINcoBOOST X4 symmetric 600 400 IGBT3 VINco X4 Al2O3 Module datasheet:PDF
Symm. Boost-KE-Cap-NTC
VINcoBOOST X4 symmetric
10-FX062TA099FS-P980D57 Series production PFC (Single-phase applications) Dual Boost PFC-Half Controlled-Shunt-Cap-NTC flowPFC 0 600 36 Infineon CoolMOS™ C6 flow 0 17 Al2O3 Module datasheet:PDF
Dual Boost PFC-Half Controlled-Shunt-Cap-NTC
flowPFC 0
80-M3166BA140SC02-K489G40 In qualification Rectifier (+Brake) 3ph-Rectifier-BRC-NTC MiniSKiiP® CON 3 1200 140 Thyristor (SCR) MiniSKiiP® 3 16 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC-NTC
MiniSKiiP CON 3
V23990-P629-L48Y-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-FZ07NBA100SM10-M305L68 Series production Booster Symmetric Symm. Boost-KE-NTC flowBOOST 0 symmetric 650 100 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Symm. Boost-KE-NTC
flowBOOST 0 symmetric
80-M3166BA140SC03-K489G42 In qualification Rectifier (+Brake) 3ph-Rectifier-BRC-NTC MiniSKiiP® CON 3 1200 140 Thyristor (SCR) MiniSKiiP® 3 16 Si3N4 Module datasheet:PDF
3ph-Rectifier-BRC-NTC
MiniSKiiP CON 3
10-PC124PA040MR-L638F18Y Series production H-Bridge 2xHalf Bridge-KE-NTC fastPACK 0 SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
2xHalf Bridge-KE-NTC
fastPACK 0 SiC
10-PZ074PA030SM-L623F08Y Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 0 H C 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 0 H C
V23990-P623-L82-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-PZ074PA050SM-L624F08Y Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 0 H C 650 50 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 0 H C
10-PZ074PA075SM-L625F08Y Series production H-Bridge H-Bridge-KE-OE-Cap-NTC fastPACK 0 H C 650 75 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-Cap-NTC
fastPACK 0 H C
80-M3166BA125AS-K489G30 In qualification Rectifier (+Brake) 3ph-Rectifier-BRC-NTC MiniSKiiP® CON 3 1200 125 Thyristor (SCR) MiniSKiiP® 3 16 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC-NTC
MiniSKiiP CON 3
V23990-P623-F59-PM In qualification H-Bridge H-Bridge-KE-NTC fastPACK 0 H 650 50 IGBT H5 flow 0 17 Al2O3 Module datasheet:PDF
H-Bridge-KE-NTC
fastPACK 0 H
V23990-P640-G08Y-PM In qualification Rectifier (+Brake) 3ph-Rectifier-BRC flowCON 0 1600 75 Rectifier flow 0 12 Al2O3 Module datasheet:PDF
3ph-Rectifier-BRC
flowCON 0
10-FY074PA050SM-M582F38 Series production H-Bridge H-Bridge-KE-OE-NTC flowPACK 1 H 650 50 IGBT H5 flow 1 12 Al2O3 Module datasheet:PDF
H-Bridge-KE-OE-NTC
flowPACK 1 H
V23990-P629-L48-PM Series production Booster Dual Boost-KE-OE-Bypass diode-NTC flowBOOST 0 dual 1200 40 IGBT4 HS flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-OE-Bypass diode-NTC
flowBOOST 0 dual
10-PZ12B2A040ME01-M330L63Y In qualification Booster Dual Boost-KE-Cap-NTC flowBOOST 0 SiC 1200 35 SiC MOSFET flow 0 12 Al2O3 Module datasheet:PDF
Dual Boost-KE-Cap-NTC
flowBOOST 0 SIC
10-FZ07BIA030SM02-P894E58 Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
10-PZ07BIA030SM02-P894E58Y Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
10-PZ07BIA030SM01-P894E68Y Series production Single-phase Inverter Booster + H-Bridge-KE-NTC flowSOL 0 BI (TL) 650 30 IGBT H5 flow 0 12 Al2O3 Module datasheet:PDF
Booster + H-Bridge-KE-NTC
flowSOL 0 BI (TL)
