Vincotech offers power integrated modules (PIM/CIB – converter, inverter and brake), sixpacks (three-phase modules), half-bridges and rectifier modules engineered to support standard drive applications for industrial use and motor power ranges from 1 kW to 60 kW.
- Topology
- Sub-Topology
-
Product line
-
Voltage in V
-
Current in A
-
Main Chip technology
- Housing Family
-
Height in mm
Part-no details / Part-no datasheet | Product status | Topology | Sub-Topology | Product line | Voltage in V |
Current in A |
Main Chip technology | Housing family | Height in mm |
Isolation | Simulation | ||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
10- |
Series production | Sevenpack | IB-OE-KE-NTC | flow7PACK 1 | 1200 | 25 | IGBT4 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Half-Bridge | Half Bridge-NTC | flowPHASE 0 + NTC | 1200 | 100 | IGBT4 | flow 0 | 17 | AlN | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flow90PIM 1 | 600 | 6 | IGBT3 | flow 90 1 | Al2O3 | On demand |
![]() ![]() |
||
10- |
Series production | Sevenpack | IB-OE-KE-NTC | flow7PACK 1 | 1200 | 35 | IGBT4 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
In qualification | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 3 | 1200 | 200 | IGBT M7 | MiniSKiiP® 3 | 16 | Si3N4 | On demand |
![]() ![]() |
|
80- |
Series production | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 2 | 1200 | 75 | IGBT M7 | MiniSKiiP® 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Half-Bridge | Half-Bridge-NTC | flowDUAL E1 SiC | 1200 | 50 | SiC MOSFET | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flow90PIM 1 | 600 | 15 | IGBT3 | flow 90 1 | Al2O3 | On demand |
![]() ![]() |
||
30- |
Series production | Sevenpack | Inverter-OE-KE-Brake-NTC | flow7PACK 2 | 1200 | 50 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | MiniSKiiP® PIM 1 | 600 | 10 | IGBT3 | MiniSKiiP® 1 | 16 | Al2O3 | On demand |
![]() ![]() |
|
30- |
Series production | Sevenpack | Inverter-OE-KE-Brake-NTC | flow7PACK 2 | 1200 | 100 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 1200 | 35 | IGBT M7 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 2 | 1200 | 35 | IGBT M7 | MiniSKiiP® 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flow90PIM 1 | 600 | 30 | IGBT3 | flow 90 1 | Al2O3 | On demand |
![]() ![]() |
||
10- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 1200 | 35 | IGBT M7 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 2 | 1200 | 50 | IGBT M7 | MiniSKiiP® 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
70- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | VINcoNPC X12 | 1200 | 1200 | IGBT4 HS | VINco X12 | Al2O3 | On demand |
![]() ![]() |
||
10- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 100 | IGBT M7 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 2 | 1200 | 100 | IGBT M7 | MiniSKiiP® 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 3 | 1200 | 100 | IGBT M7 | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level MNPC (T-Type) | MNPC (T-type)-KE-NTC | flowMNPC 1 | 650 | 150 | IGBT S5 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sevenpack | IB-OE-NTC | flow7PACK 0 | 1200 | 8 | IGBT4 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-Tandem Diode-NTC | flowPIM® 1 | 1200 | 25 | IGBT4 HS | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 75 | IGBT M7 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sevenpack | IB-OE-NTC | flow7PACK 0 | 1200 | 15 | IGBT4 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM+PFC (CIP) | IP-OE-NTC | flowPIM® 1 + PFC | 600 | 50 | IGBT fast | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
In qualification | Rectifier (+Brake) | 3ph-Non Controlled-BRC-KE-NTC | flowCON 1 | 1600 | 170 | Rectifier | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 0 IGBT | 650 | 75 | IGBT H5 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 1 | 650 | 150 | IGBT3 HS | flow 1 | 17 | AlN | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sevenpack | IB-OE-NTC | flow7PACK 0 | 1200 | 25 | IGBT4 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM+PFC (CIP) | CIP-OE-Shunt-NTC | flowPIM® 1 + PFC | 600 | 30 | IGBT fast | flow 1 | 12 | Al2O3 | On demand |
![]() ![]() |
|
80- |
Series production | PIM (CIB) | CIB-OE-NTC | MiniSKiiP® PIM 1 | 1200 | 10 | IGBT M7 | MiniSKiiP® 1 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level MNPC (T-Type) | MNPC (T-type)-KE-NTC | flowMNPC 0 | 1200 | 80 | IGBT4 HS | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level MNPC (T-Type) | MNPC (T-type)-KE-NTC | flowMNPC 0 | 1200 | 80 | IGBT4 HS | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | Half-Bridge | Half Bridge-NTC | MiniSKiiP® DUAL 3 | 1200 | 400 | IGBT4 | MiniSKiiP® DUAL 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Rectifier-BRC | flowCON 0 | 1600 | 50 | Rectifier | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 100 | IGBT M7 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 50 | IGBT4 | flow 1 | 17 | AlN | Simulate this module |
![]() ![]() |
|
80- |
Series production | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 3 | 1200 | 200 | IGBT M7 | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-NTC | flowPACK E2 | 1200 | 75 | IGBT M7 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 75 | IGBT M7 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CI-OE-NTC | flowPIM® E2 | 1200 | 63 | SiC MOSFET | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-OE-KE-NTC | flow90PACK 1 | 600 | 50 | IGBT3 | flow 90 1 | Al2O3 | On demand |
![]() ![]() |
||
10- |
In qualification | Sixpack | Inverter-KE- Cap-NTC | flowPACK 1 SiC | 1200 | 100 | SiC MOSFET | flow 1 | 12 | Si3N4 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-NTC | flowPACK E2 | 1200 | 75 | IGBT M7 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-OE-KE-NTC | flow90PACK 1 | 600 | 75 | IGBT3 | flow 90 1 | Al2O3 | On demand |
![]() ![]() |
||
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-CAP-NTC | flowNPC 1 | 650 | 150 | IGBT H5 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
30- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 2 | 650 | 200 | IGBT S5 | flow 2 | 13 | Al2O3 | Simulate this module |
![]() ![]() |
|
20- |
Series production | IPM (CIB) | CIB-OE-NTC | flowIPM 1B (CI) | 1200 | 8 | IGBT4 | flow 1B | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-CAP-NTC | flowNPC 1 | 650 | 150 | IGBT H5 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 600 | 6 | IGBT3 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 3 | 1200 | 100 | IGBT4 | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
30- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 2 | 650 | 200 | IGBT S5 | flow 2 | 13 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | Half-Bridge | Half Bridge-NTC | MiniSKiiP® DUAL 2 | 1200 | 300 | IGBT M7 | MiniSKiiP® DUAL 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CI-OE-NTC | flowPIM® E2 | 1200 | 35 | IGBT M7 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
30- |
Series production | Rectifier (+Brake) | 3ph-Half Controlled-BRC | flowCON 2 | 1600 | 150 | Rectifier | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
20- |
Series production | IPM (CIB) | CIB-OE-NTC | flowIPM 1B (CI) | 1200 | 15 | IGBT4 | flow 1B | 17 | Al2O3 | On demand |
![]() ![]() |
|
A0- |
Series production | Half-Bridge | Half Bridge-NTC | VINcoDUAL E3 | 1200 | 300 | IGBT M7 | VINco E3s | 17 | IMB | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® E1 | 1200 | 25 | IGBT M7 | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® E2 | 1200 | 25 | IGBT4 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® E2 | 1200 | 25 | IGBT M7 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM+PFC (CIP) | CIP-OE-Shunt-NTC | flowPIM® 0 + PFC | 600 | 10 | Infineon CoolMOS™ C6 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 1200 | 15 | IGBT4 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | PIM (CIB) | CIB-KE-NTC | MiniSKiiP® PIM 2 | 1200 | 35 | IGBT M7 | MiniSKiiP® 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® E2 | 1200 | 35 | IGBT M7 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Half Controlled-BRC | flow90CON 1 | 1600 | 36 | Thyristor (SCR) | flow 90 1 | Al2O3 | Simulate this module |
![]() ![]() |
||
A0- |
Series production | Sixpack | Inverter-KE-NTC | VINcoPACK E3 | 1200 | 100 | IGBT M7 | VINco E3 | 17 | IMB | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CI-OE-NTC | flowPIM® 0 | 1200 | 8 | IGBT4 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | MiniSKiiP® PIM 1 | 1200 | 8 | IGBT4 | MiniSKiiP® 1 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® E2 | 1200 | 35 | IGBT M7 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Rectifier-BRC-NTC | flow90CON 1 | 1600 | 39 | Rectifier | flow 90 1 | Al2O3 | Simulate this module |
![]() ![]() |
||
30- |
In qualification | Sixpack | 3xHalf Bridge-OE-KE-NTC | flowPACK 2 | 1200 | 100 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
A0- |
Series production | Sixpack | Inverter-KE-NTC | VINcoPACK E3 | 1200 | 150 | IGBT M7 | VINco E3 | 17 | IMB | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CI-OE-NTC | flowPIM® 0 | 1200 | 15 | IGBT4 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-KE-NTC | MiniSKiiP® PIM 3 | 1200 | 50 | IGBT4 | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
In qualification | Rectifier (+Brake) | 3ph-Rectifier-BRC-NTC | flow90CON 1 | 1200 | 100 | IGBT4 | flow 90 1 | Al2O3 | Simulate this module |
![]() ![]() |
||
V23990- |
Series production | Rectifier (+Brake) | 3ph-Non Controlled-NTC | flow90CON 1 | 1600 | 36 | Thyristor (SCR) | flow 90 1 | Al2O3 | Simulate this module |
![]() ![]() |
||
30- |
In qualification | Sixpack | 3xHalf Bridge-OE-KE-NTC | flowPACK 2 | 1200 | 150 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
A0- |
Series production | Sixpack | Inverter-KE-NTC | VINcoPACK E3 | 1200 | 200 | IGBT M7 | VINco E3 | 17 | IMB | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-KE-NTC | flowPACK E1 | 1200 | 50 | IGBT M7 | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-KE-NTC | MiniSKiiP® PIM 3 | 1200 | 75 | IGBT4 | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Full Controlled-BRC-NTC | flow90CON 1 | 1600 | 52 | Rectifier | flow 90 1 | Al2O3 | Simulate this module |
![]() ![]() |
||
20- |
Series production | IPM (CIP/PIM+PFC) | CIP-NTC | flowIPM 1B (CIP) | 600 | 10 | IGBT RC | flow 1B | 17 | Al2O3 | On demand |
![]() ![]() |
|
10- |
Series production | Half-Bridge | Half-Bridge-NTC | flowDUAL E2 SiC | 1200 | 250 | SiC MOSFET | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Rectifier-BRC-NTC-Thyristor | flow90CON 1 | 1600 | 43 | Thyristor (SCR) | flow 90 1 | Al2O3 | On demand |
![]() ![]() |
||
80- |
Series production | Sixpack | Inverter-OE-NTC | MiniSKiiP® PACK 1 | 1200 | 10 | IGBT M7 | MiniSKiiP® 1 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® E2 | 1200 | 35 | IGBT4 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Full Controlled-BRC-NTC | flow90CON 1 | 1600 | 75 | Rectifier | flow 90 1 | Al2O3 | Simulate this module |
![]() ![]() |
||
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 1200 | 4 | IGBT4 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | Half-Bridge | Half Bridge-NTC | MiniSKiiP® DUAL 2 | 1200 | 200 | IGBT4 | MiniSKiiP® DUAL 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-NTC | flowPACK E2 | 1200 | 75 | IGBT4 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Rectifier-BRC | flowCON 0 | 1600 | 75 | Rectifier | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-KE-NTC | MiniSKiiP® PIM 2 | 1200 | 25 | IGBT4 | MiniSKiiP® 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Full Controlled-BRC-NTC | flowCON 0 | 1600 | 75 | Rectifier | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
70- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | VINcoNPC X12 | 1200 | 1200 | IGBT M7 | VINco X12 | Al2O3 | Simulate this module |
![]() ![]() |
||
A0- |
Series production | Sixpack | Inverter-KE-Tandem Diode-NTC | VINcoPACK E3 | 1200 | 200 | IGBT4 HS | VINco E3 | 17 | IMB | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 1200 | 15 | IGBT4 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM+PFC (CIP) | CIP-OE-Shunt-NTC | flowPIM® 1 + PFC | 600 | 20 | IGBT fast | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 2 | 1200 | 35 | IGBT4 | MiniSKiiP® 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-NTC | flowPACK E2 | 1200 | 75 | IGBT M7 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 1ph-Non-Controlled–NTC | flowCON 0 | 1600 | 50 | Rectifier | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 75 | IGBT4 HS | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
In qualification | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 1 | 600 | 100 | IGBT3 | flow 1 | 12 | Al2O3 | On demand |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 1200 | 15 | IGBT4 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level MNPC (T-Type) | MNPC (T-type)-KE-NTC | flowMNPC 0 | 1200 | 80 | IGBT fast | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-KE-NTC | MiniSKiiP® PIM 3 | 1200 | 100 | IGBT4 | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 1200 | 35 | IGBT M7 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | PIM (CIB) | CIB-OE-NTC | MiniSKiiP® PIM 1 | 1200 | 25 | IGBT M7 | MiniSKiiP® 1 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 0 | 600 | 15 | IGBT3 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 1200 | 8 | IGBT4 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | Sixpack | Inverter-OE-NTC | MiniSKiiP® PACK 1 | 1200 | 25 | IGBT M7 | MiniSKiiP® 1 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | PIM (CIB) | CIB-KE-NTC | MiniSKiiP® PIM 2 | 1200 | 50 | IGBT M7 | MiniSKiiP® 2 | 16 | Al2O3 | On demand |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 1200 | 15 | IGBT4 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CI-OE-NTC | flowPIM® E1 | 1200 | 15 | IGBT4 | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | Sixpack | Inverter-OE-NTC | MiniSKiiP® PACK 1 | 1200 | 35 | IGBT M7 | MiniSKiiP® 1 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-NTC | flowPACK E2 | 1200 | 100 | IGBT M7 | flow E2 | 12 | Al2O3 | On demand |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CI-OE-NTC | flowPIM® 0 | 1200 | 15 | IGBT4 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-KE-NTC | MiniSKiiP® PIM 3 | 600 | 75 | IGBT3 | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CI-OE-NTC | flowPIM® E1 | 1200 | 15 | IGBT M7 | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level MNPC (T-Type) | MNPC (T-type)-KE-NTC | flowMNPC 0 | 1200 | 80 | IGBT4 HS | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level MNPC (T-Type) | MNPC (T-type)-KE-NTC | flowMNPC E2 SiC | 1200 | 120 | SiC MOSFET | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Half Controlled-BRC | flowCON 0 | 1600 | 42 | Thyristor (SCR) | flow 0 | 17 | Al2O3 | On demand |
![]() ![]() |
|
80- |
In qualification | Half-Bridge | Half Bridge-NTC | MiniSKiiP® DUAL 2 | 1200 | 200 | IGBT4 | MiniSKiiP® DUAL 2 | 16 | Si3N4 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Half Controlled-BRC | flowCON 0 | 1600 | 42 | Thyristor (SCR) | flow 0 | 17 | Al2O3 | On demand |
![]() ![]() |
|
10- |
Series production | PIM+PFC (CIP) | CIP-OE-NTC | flowPIM® 0B + PFC | 600 | 10 | IGBT RC | flow 0B | 17 | Al2O3 | On demand |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Half Controlled-BRC | flowCON 0 | 1600 | 34 | Thyristor (SCR) | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
30- |
Series production | Sixpack | 3xHalf Bridge-OE-KE-NTC | flowPACK 2 | 1200 | 150 | IGBT4 HS | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Half Controlled-BRC | flowCON 0 | 1600 | 34 | Thyristor (SCR) | flow 0 | 17 | Al2O3 | On demand |
![]() ![]() |
|
10- |
Series production | Three-level MNPC (T-Type) | MNPC (T-type)-KE-Split Output-Cap-NTC | flowMNPC 1 | 1200 | 160 | IGBT4 HS | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
In qualification | Sixpack | Twin inverters-NTC | MiniSKiiP® Twin 2 | 1200 | 50 | IGBT M7 | MiniSKiiP® 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 2 | 1200 | 100 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 1200 | 25 | IGBT M7 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 2 | 600 | 75 | IGBT3 | flow 2 | 17 | Al2O3 | On demand |
![]() ![]() |
|
10- |
In qualification | Sixpack | Inverter-OE-NTC | flowPACK 0B | 600 | 30 | IGBT3 LL | flow 0B | 12 | Al2O3 | On demand |
![]() ![]() |
|
80- |
Series production | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 3 | 1200 | 200 | IGBT M7 | MiniSKiiP® 3 | 16 | Si3N4 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 0 IGBT | 1200 | 30 | IGBT3 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 2 | 600 | 100 | IGBT3 | flow 2 | 17 | Al2O3 | On demand |
![]() ![]() |
|
20- |
Series production | IPM (CIP/PIM+PFC) | CIP-NTC | flowIPM 1B (CIP) | 600 | 10 | IGBT RC | flow 1B | 17 | Al2O3 | On demand |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® E2 | 1200 | 50 | IGBT M7 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | PIM (CIB) | CIB-KE-Tandem Diode-NTC | MiniSKiiP® PIM 3 | 1200 | 100 | IGBT M7 | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
In qualification | Sixpack | Twin inverters-OE-NTC | MiniSKiiP® PACK 3 | 1200 | 50 | IGBT4 | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 2 | 1200 | 35 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
B0- |
Series production | Three-level NPC (I-Type) | NPC-Split-KE-Pos-NTC | flowNPC S3 split | 950 | 600 | IGBT S7 | flow S3 | 12 | AlN | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 0 IGBT | 600 | 75 | IGBT3 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 2 | 1200 | 50 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-KE-NTC | MiniSKiiP® PIM 3 | 1200 | 35 | IGBT4 | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
B0- |
Series production | Three-level NPC (I-Type) | NPC-Split-KE-Neg-NTC | flowNPC S3 split | 950 | 600 | IGBT S7 | flow S3 | 12 | AlN | Simulate this module |
![]() ![]() |
|
10- |
In qualification | Three-level MNPC (T-Type) | MNPC (T-type)-KE-NTC | flowMNPC 0 | 1200 | 80 | IGBT fast | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 2 | 1200 | 75 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 3 | 1200 | 150 | IGBT4 | MiniSKiiP® 3 | 16 | Si3N4 | Simulate this module |
![]() ![]() |
|
B0- |
Series production | Three-level NPC (I-Type) | NPC-Split-KE-Pos-NTC | flowNPC S3 split | 950 | 600 | IGBT S7 | flow S3 | 12 | AlN | Simulate this module |
![]() ![]() |
|
10- |
In qualification | Three-level MNPC (T-Type) | MNPC (T-type)-KE-NTC | flowMNPC 0 | 1200 | 80 | IGBT fast | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 600 | 75 | IGBT3 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
In qualification | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 25 | IGBT M7 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
B0- |
Series production | Three-level NPC (I-Type) | NPC-Split-KE-Neg-NTC | flowNPC S3 split | 950 | 600 | IGBT S7 | flow S3 | 12 | AlN | Simulate this module |
![]() ![]() |
|
30- |
In qualification | Sixpack | 3xHalf Bridge-OE-KE-NTC | flowPACK 2 | 1200 | 75 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
30- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 2 | 650 | 300 | IGBT S5 | flow 2 | 13 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 1 | 650 | 200 | IGBT S5 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-KE-NTC | flowPACK E1 | 600 | 50 | IGBT3 | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | PIM (CIB) | CIB-OE-NTC | MiniSKiiP® PIM 2 | 1200 | 15 | IGBT4 | MiniSKiiP® 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 1 | 1200 | 200 | IGBT S5 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 600 | 50 | IGBT3 | flow 1 | 17 | AlN | On demand |
![]() ![]() |
|
30- |
In qualification | Sixpack | 3xHalf Bridge-OE-KE-NTC | flowPACK 2 | 1200 | 50 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-KE-NTC | flowPACK E1 | 1200 | 35 | IGBT M7 | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-NTC | flowPACK E2 | 1200 | 50 | IGBT M7 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 600 | 50 | IGBT3 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | PIM (CIB) | CIB-KE-NTC | MiniSKiiP® PIM 3 | 1200 | 100 | IGBT M7 | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 0 IGBT | 600 | 30 | IGBT3 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level MNPC (T-Type) | MNPC (T-type)-KE-NTC | flowMNPC 0 | 1200 | 80 | IGBT fast | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
70- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | VINcoNPC X12 | 1200 | 1200 | IGBT4 | VINco X12 | Al2O3 | On demand |
![]() ![]() |
||
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-CAP-NTC | flowNPC 1 | 650 | 150 | IGBT H5 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CI-OE-NTC | flowPIM® 0 | 1200 | 4 | IGBT4 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 600 | 100 | IGBT3 | flow 1 | 17 | Al2O3 | On demand |
![]() ![]() |
|
70- |
Series production | Three-level MNPC (T-Type) | MNPC (T-type)-KE-NTC | VINcoMNPC X12 | 1200 | 1800 | IGBT4 | VINco X12 | Al2O3 | On demand |
![]() ![]() |
||
10- |
Series production | PIM+PFC (CIP) | CIP-OE-Shunt-NTC | flowPIM® 1 + PFC | 600 | 50 | IGBT fast | flow 1 | 12 | Al2O3 | On demand |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 35 | IGBT4 | flow 1 | 17 | AlN | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | MiniSKiiP® PIM 1 | 1200 | 15 | IGBT4 | MiniSKiiP® 1 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 1200 | 25 | IGBT4 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 35 | IGBT4 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CI-OE-NTC | flow90PIM 1 | 1200 | 15 | IGBT M7 | flow 90 1 | Al2O3 | Simulate this module |
![]() ![]() |
||
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 50 | IGBT4 | flow 1 | 17 | AlN | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 50 | IGBT4 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 1200 | 25 | IGBT M7 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 50 | IGBT4 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
A0- |
Series production | Half-Bridge | Half Bridge-NTC | VINcoDUAL E3 | 1200 | 450 | IGBT M7 | VINco E3s | 17 | IMB | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 75 | IGBT4 | flow 1 | 17 | AlN | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-CAP-NTC | flowNPC 1 | 650 | 150 | IGBT S5 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
30- |
Series production | Three-level MNPC (T-Type) | MNPC (T-type)-KE-Split Output-NTC | flowMNPC 2 | 1200 | 200 | IGBT4 HS | flow 2 | 13 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CI-OE-KE-NTC | flowPIM® 1 | 1200 | 35 | IGBT4 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
30- |
Series production | Rectifier (+Brake) | 3ph-Rectifier-BRC-NTC | flowCON 2 | 1600 | 150 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 1200 | 4 | IGBT4 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-KE-NTC | flowPACK E1 SiC | 1200 | 20 | SiC MOSFET | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 1200 | 8 | IGBT4 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
70- |
In qualification | Three-level NPC (I-Type) | NPC-KE-NTC | VINcoNPC X12 | 1200 | 1800 | IGBT M7 | VINco X12 | Al2O3 | Simulate this module |
![]() ![]() |
||
80- |
Series production | Sixpack | Twin inverters-OE-NTC | MiniSKiiP® Twin 3 | 1200 | 50 | IGBT4 HS | MiniSKiiP® 3 | 16 | Al2O3 | On demand |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CI-OE-KE-NTC | flowPIM® 1 | 1200 | 35 | IGBT M7 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 1200 | 25 | IGBT M7 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 1200 | 35 | IGBT4 | flow 1 | 17 | AlN | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 600 | 15 | IGBT3 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Discontinued | Three-level MNPC (T-Type) | MNPC (T-type)-KE-Split Output-Cap-NTC | flowMNPC 1 | 1200 | 160 | IGBT4 HS | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 1 | 650 | 150 | IGBT S5 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-OE-KE-NTC | flow90PACK 1 | 600 | 30 | Trench Field Stop II IGBT | flow 90 1 | Al2O3 | On demand |
![]() ![]() |
||
10- |
Discontinued | Three-level MNPC (T-Type) | MNPC (T-type)-KE-Split Output-Cap-NTC | flowMNPC 1 | 1200 | 160 | IGBT4 HS | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 0 | 600 | 50 | IGBT3 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 1 | 600 | 100 | IGBT3 | flow 1 | 12 | Al2O3 | On demand |
![]() ![]() |
|
A0- |
Series production | Half-Bridge | Half Bridge-NTC | VINcoDUAL E3 | 1200 | 200 | IGBT M7 | VINco E3s | 17 | IMB | Simulate this module |
![]() ![]() |
|
10- |
In qualification | PIM+PFC (CIP) | Rectifier + Dual Booster + H-Bridge-KE-OE-NTC | flowRPI 1 | 600 | 20 | Infineon CoolMOS™ CFD7 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 0 | 600 | 75 | IGBT3 | flow 0 | 12 | Al2O3 | On demand |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-CAP-NTC | flowNPC 1 | 650 | 80 | IGBT H5 | flow 1 | 12 | Al2O3 | On demand |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-OE-KE-NTC | flow90PACK 1 | 1200 | 35 | IGBT4 | flow 90 1 | Al2O3 | Simulate this module |
![]() ![]() |
||
10- |
In qualification | Three-level MNPC (T-Type) | MNPC (T-type)-KE-NTC | flowMNPC E2 SiC | 1200 | 120 | SiC MOSFET | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-OE-KE-NTC | flow90PACK 1 | 1200 | 50 | IGBT4 | flow 90 1 | Al2O3 | Simulate this module |
![]() ![]() |
||
10- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 1200 | 35 | IGBT M7 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM+PFC (CIP) | IP-OE-Shunt-NTC | flowPIM® 1 + PFC | 600 | 30 | IGBT fast | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 0 | 1200 | 25 | IGBT4 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CI-OE-KE-NTC | flowPIM® 1 | 1200 | 15 | IGBT4 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM+PFC (CIP) | IP-OE-Shunt-NTC | flowPIM® 1 + PFC | 600 | 50 | IGBT fast | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | Sixpack | Inverter-OE-NTC | MiniSKiiP® PACK 1 | 1200 | 15 | IGBT M7 | MiniSKiiP® 1 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 0 | 600 | 30 | IGBT3 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 0 | 600 | 10 | IGBT3 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CI-OE-NTC | flowPIM® E1 | 1200 | 10 | IGBT M7 | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Rectifier-BRC | flow90CON 1 | 1600 | 42 | Rectifier | flow 90 1 | Al2O3 | Simulate this module |
![]() ![]() |
||
10- |
Series production | Sixpack | Inverter-OE-KE-NTC | flowPACK E1 | 1200 | 25 | IGBT M7 | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 0 | 600 | 50 | IGBT3 | flow 0 | 17 | Al2O3 | On demand |
![]() ![]() |
|
80- |
Series production | Half-Bridge | Half Bridge-NTC | MiniSKiiP® DUAL 2 | 1200 | 200 | IGBT M7 | MiniSKiiP® DUAL 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
In qualification | Half-Bridge | Half Bridge-NTC | MiniSKiiP® DUAL 2 | 1200 | 200 | IGBT4 | MiniSKiiP® DUAL 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 0 | 1200 | 15 | IGBT4 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® E2 | 600 | 50 | IGBT3 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 0 | 1200 | 35 | IGBT M7 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-Split-KE-Pos-NTC | flowNPC 1 split | 1200 | 150 | IGBT4 HS | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 600 | 30 | IGBT3 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-KE-NTC | flowPACK E1 | 1200 | 25 | IGBT M7 | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-Split-KE-Neg-NTC | flowNPC 1 split | 1200 | 150 | IGBT4 HS | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 0 | 1200 | 35 | IGBT4 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 0 | 600 | 50 | IGBT3 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 0 | 600 | 75 | IGBT3 | flow 0 | 12 | Al2O3 | On demand |
![]() ![]() |
|
80- |
Series production | Rectifier (+Brake) | 3ph-Half Controlled-BRC-NTC | MiniSKiiP® CON 2 | 1200 | 75 | IGBT M7 | MiniSKiiP® 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flow90PIM 1 | 1200 | 15 | IGBT M7 | flow 90 1 | Al2O3 | Simulate this module |
![]() ![]() |
||
30- |
Series production | Sixpack | 3xHalf Bridge-OE-KE-NTC | flowPACK 2 | 1200 | 150 | IGBT M7 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-NTC | flowPACK E2 | 600 | 100 | IGBT3 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CI-OE-NTC | flowPIM® 0 | 1200 | 5 | IGBT M7 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 600 | 6 | IGBT3 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® E1 | 1200 | 10 | IGBT M7 | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level MNPC (T-Type) | 3xMNPC (T-type)-KE-NTC | flow3xMNPC 1 | 1200 | 25 | IGBT4 HS | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
In qualification | Three-level MNPC (T-Type) | MNPC (T-type)-KE-Cap-NTC | flowMNPC 1 | 1200 | 160 | IGBT fast | flow 1 | 12 | Al2O3 | On demand |
![]() ![]() |
|
20- |
Series production | IPM (CIB) | CIB-OE-NTC | flowIPM 1B (CI) | 1200 | 8 | IGBT4 | flow 1B | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® E1 | 1200 | 15 | IGBT M7 | flow E1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Rectifier (+Brake) | 3ph-Non Controlled-BRC-KE-NTC | flowCON 0 | 1600 | 50 | Rectifier | flow 0 | 17 | Al2O3 | On demand |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 600 | 15 | IGBT3 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® E2 | 1200 | 15 | IGBT M7 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 600 | 15 | IGBT3 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
30- |
In qualification | Sixpack | 3xHalf Bridge-OE-KE-Tandem Diode-NTC | flowPACK 2 | 1200 | 75 | IGBT M7 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 600 | 20 | IGBT3 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 75 | IGBT4 | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-NTC | flowPACK E2 | 1200 | 50 | IGBT M7 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
B0- |
In qualification | PIM (CIB) | CIB-OE-NTC | flowPIM® S3 | 1200 | 100 | IGBT M7 | flow S3 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
In qualification | PIM+PFC (CIP) | CIP-OE-Shunt-NTC | flowPIM® 0 + PFC | 600 | 20 | IGBT F5 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
30- |
In qualification | Sixpack | 3xHalf Bridge-OE-KE-Tandem Diode-NTC | flowPACK 2 | 1200 | 100 | IGBT M7 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 1200 | 8 | IGBT4 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-NTC | flowPACK E2 | 1200 | 100 | IGBT M7 | flow E2 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
B0- |
In qualification | Sixpack | Inverter-OE-KE-NTC | flowPACK S3 | 1200 | 200 | IGBT M7 | flow S3 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
20- |
Series production | IPM (CIP/PIM+PFC) | CIP-NTC | flowIPM 1B (CIP) | 600 | 10 | IGBT RC | flow 1B | 17 | Al2O3 | On demand |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-OE-KE-NTC | flow90PACK 1 | 1200 | 15 | IGBT4 | flow 90 1 | Al2O3 | Simulate this module |
![]() ![]() |
||
70- |
Series production | Three-level MNPC (T-Type) | MNPC-Cap-NTC | VINcoMNPC X4 | 1200 | 600 | IGBT M7 | VINco X4 | Al2O3 | Simulate this module |
![]() ![]() |
||
10- |
In qualification | Three-level FC Inverter | FC-KE-NTC-Cap | flowFC 1 | 1200 | 200 | IGBT fast | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level MNPC (T-Type) | 3xMNPC (T-type)-KE-NTC | flow3xMNPC 1 | 1200 | 25 | IGBT4 HS | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM+PFC (CIP) | IP-OE-NTC | flowPIM® 1 + PFC | 600 | 30 | IGBT fast | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
In qualification | Three-level FC Inverter | FC-KE-NTC-Cap | flowFC 1 | 1200 | 200 | IGBT fast | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM+PFC (CIP) | CIP-OE-Shunt-NTC | flowPIM® 1 + PFC | 600 | 30 | IGBT fast | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | 3xHalf Bridge-OE-KE | flowPACK 2 | 1200 | 100 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
70- |
Series production | Three-level MNPC (T-Type) | MNPC-Cap-NTC | VINcoMNPC X12 | 1200 | 1800 | IGBT M7 | VINco X12 | Al2O3 | Simulate this module |
![]() ![]() |
||
V23990- |
Series production | Rectifier (+Brake) | 3ph-Rectifier | flowCON 0 | 1600 | 59 | Rectifier | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-NTC | flow90PACK 0 | 1200 | 35 | IGBT4 | flow 90 0 | Al2O3 | Simulate this module |
![]() ![]() |
||
10- |
Series production | Rectifier (+Brake) | 3ph-Rectifier | flowCON 0B | 1800 | 35 | Rectifier | flow 0B | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 2 | 1200 | 100 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Rectifier (+Brake) | 3ph-Rectifier | flowCON 0 | 1800 | 40 | Rectifier | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Rectifier (+Brake) | 3ph-Rectifier | flowCON 0 | 1800 | 60 | Rectifier | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | Half-Bridge | Half Bridge-NTC | MiniSKiiP® DUAL 2 | 1200 | 150 | IGBT4 | MiniSKiiP® DUAL 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flow90PIM 1 | 1200 | 25 | IGBT4 | flow 90 1 | Al2O3 | On demand |
![]() ![]() |
||
10- |
Series production | Three-level MNPC (T-Type) | 3xMNPC (T-type)-KE-NTC | flow3xMNPC 1 | 1200 | 25 | IGBT4 HS | flow 1 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
70- |
In qualification | Three-level NPC (I-Type) | NPC-KE-NTC | VINcoNPC X4 | 1200 | 400 | IGBT M7 | VINco X4 | Al2O3 | Simulate this module |
![]() ![]() |
||
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 0 IGBT | 600 | 50 | IGBT3 | flow 0 | 12 | Al2O3 | On demand |
![]() ![]() |
|
10- |
In qualification | Rectifier (+Brake) | 1ph-Rectifier | flowCON 0 | 1600 | 110 | Rectifier | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 0 IGBT | 600 | 75 | IGBT3 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | 3xHalf Bridge-OE-KE-NTC | flowPACK 1 SiC | 1200 | 65 | SiC MOSFET | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-NTC | flowNPC 1 | 600 | 150 | IGBT3 | flow 1 | 17 | Al2O3 | On demand |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-CAP-NTC | flowNPC 1 | 650 | 200 | IGBT H5 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 2 | 1200 | 75 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
Series production | Rectifier (+Brake) | 3ph-Rectifier-BRC-NTC | MiniSKiiP® CON 3 | 1600 | 125 | Thyristor (SCR) | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 600 | 20 | IGBT3 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level MNPC (T-Type) | MNPC (T-type)-KE-NTC | flowMNPC 1 | 650 | 150 | IGBT S5 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM+PFC (CIP) | CIP-OE-Shunt-NTC | flowPIM® 0 + PFC | 600 | 10 | Infineon CoolMOS™ C6 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 2 | 1200 | 50 | IGBT4 | flow 2 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Three-level NPC (I-Type) | NPC-KE-CAP-NTC | flowNPC 1 | 650 | 150 | IGBT H5 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 600 | 20 | IGBT3 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
30- |
In qualification | Three-level NPC (I-Type) | NPC-Split-KE-NTC | flowNPC 2 | 950 | 400 | IGBT S7 | flow 2 | 13 | AlN | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 3 | 1200 | 75 | IGBT4 | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM+PFC (CIP) | CIP-OE-NTC | flowPIM® 0B + PFC | 600 | 10 | IGBT RC | flow 0B | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
30- |
In qualification | Three-level NPC (I-Type) | NPC-Split-KE-NTC | flowNPC 2 | 950 | 400 | IGBT S7 | flow 2 | 13 | Si3N4 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 600 | 50 | IGBT3 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 1200 | 25 | IGBT4 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | flowPACK 1 | 1200 | 35 | IGBT4 | flow 1 | 17 | AlN | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 1200 | 10 | IGBT M7 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Rectifier (+Brake) | 3ph-Rectifier-BRC | flowCON 0 | 1600 | 75 | Rectifier | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
80- |
In qualification | Rectifier (+Brake) | 3ph Rectifier-NTC | MiniSKiiP® CON 3 | 1600 | 110 | Rectifier | MiniSKiiP® 3 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CIB-OE-NTC | flowPIM® 0 | 1200 | 8 | IGBT4 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM (CIB) | CIB-OE-KE-NTC | flowPIM® 1 | 1200 | 50 | IGBT M7 | flow 1 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CI-OE-NTC | flowPIM® 0 | 1200 | 8 | IGBT4 | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM+PFC (CIP) | IP-OE-Shunt-NTC | flowPIM® 0 + PFC | 600 | 30 | IGBT fast | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | PIM (CIB) | CI-OE-NTC | flowPIM® 0 | 1200 | 15 | IGBT4 | flow 0 | 12 | Al2O3 | Simulate this module |
![]() ![]() |
|
V23990- |
Series production | Sixpack | Inverter-KE-NTC | MiniSKiiP® PACK 2 | 1200 | 50 | IGBT4 | MiniSKiiP® 2 | 16 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | Sixpack | Inverter-OE-KE-NTC | flowPACK 0 | 1200 | 15 | IGBT4 HS | flow 0 | 17 | Al2O3 | Simulate this module |
![]() ![]() |
|
10- |
Series production | PIM+3xPFC (CIP) | 3ph Advanced Neutral PFC-Inverter-OE-NTC | flowPIM® 1 + 3xPFC | 1200 | 15 | IGBT F5 | flow 1 |
