flowIPM 1B (CIP)

基本信息

• 产品线: flowIPM 1B (CIP)
• 产品状态: Series
• 标准包装数量: 100

电气特性

• 电压: 600 V
• 电流: 10 A

IPM (CIP/PIM+PFC)

• Converter+PFC+Inverter
• Gate Drive Circuit including complete Bootstrap Circuit
• Integrated DC capacitor
• Inverter Shunt
• PFC Shunt
• Temperature sensor

芯片与隔离特性

IGBT RC

• Optimised collector emitter saturation voltage and forward voltage for low conduction losses
• Reverse conductive IGBT technology
• Smooth switching performance leading to low EMI levels

隔离

• 基础隔离:

机械与封装特性

flow 1B

• PCB机械连接方式: 4 towers
• 封装尺寸: 72 mm x 36 mm
• 高度: 17 mm
• 引脚类型: Solder pin
